Service—Every 1250 Hours
PY80265,05I0233 –19–11JUL06–1/1
Clean Transmission-Hydraulic Pickup Screen
PY2250
–UN–16MAR04
PY2251
–UN–16MAR04
A—Cap Screws (2 used)
B—Screen Cover
C—Dipstick
Remove two cap screws (A) and remove screen cover
(B).
1. Drain transmission-hydraulic oil. (See Change
Transmission-Hydraulic Oil and Filter in this section.)
2. Remove two cap screws (A) and remove screen.
Examine screen for damage. Replace if necessary.
Clean screen in solvent and blow dry with compressed
air.
3. Carefully install screen so the front of screen is
inserted in hole at front of differential case.
4. Fill system with transmission-hydraulic oil. (See
Changing Transmission-Hydraulic Oil and Filter in this
section.)
5. Check oil level at dipstick (C) after filling and again
after operating for 5 minutes.
