Service—Every 10 Hours
PY80265,05I0210 –19–12SEP05–1/1
Water Separator Bowl
PY4285
–UN–06DEC04
PY4300
–UN–06DEC04
A—Hose from Fuel Tank to Water Separator
B—Hose from Water Separator to Fuel Filter
C—Water Separator
D—Drain Screw
1. The water separator is used to obtain the better
functioning of fuel system.
2. Drain water and contaminants from clear water
separator sediment bowl by opening drain screw (D).
PY80265,05I0211 –19–12SEP05–1/1
Lubricate as Necessary
Lubrication required only when operating in extremely
wet and muddy conditions. Lubricate with several
shots of multipurpose grease specified in Fuels,
Lubricants and Coolant section.
•
Tie rod ends
•
Steering spindles (Front Axle) (See Service—50
Hours)
•
Front axle pivot pin (See Service—50 Hours)
•
Rear axle bearings (See Service—600 Hours)
•
Steering cylinder head.
