Fig. 10.2 – Jaguar S-TYPE 2004 User Manual
Page 92
The following abbreviations are used to represent values for Control Module Pin-Out data
I
Input
PG
Power Ground
C
CAN Network
D
Serial and Encoded Data
O
Output
SS
Sensor / Signal Supply V
S
SCP Network
V
Voltage (DC)
B+
Battery Voltage
SG
Sensor / Signal Ground
D2
D2B Network
PWM Pulse Width Modulated
CAUTION: The information on this data page is furnished to aid the user in understanding circuit oper ation. THIS INFORMATION SHOULD BE USED FOR
REFERENCE ONLY.
NOTE: The values listed are approximately those that can be expected at the control module connector pins with all circuit connections made and all components
connected and fitted.
Refer to the front of this book for detailed information and illustrations regarding the location and identification of harnesses, relays, fuses, grounds, control
modules and control module pins.
DATE OF ISSUE: June 2002
Fig. 10.2
COMPONENTS
Component
Connector(s)
Connector Description
Location
AIR CONDITIONING CONTROL MODULE – PANEL
FC27
26-WAY / GREY
CENTER CONSOLE
FC28
22-WAY / GREY
AIR CONDITIONING CONTROL MODULE – REMOTE
FC40
26-WAY / GREY
BEHIND INSTRUMENT PANEL, RH SIDE (LHD), LH SIDE (RHD)
FC41
22-WAY / GREY
DOOR MIRROR – DRIVER
DT6
22-WAY / BLACK
DRIVER DOOR
DOOR MIRROR – PASSENGER
CA19
22-WAY / BLACK
PASSENGER DOOR
DOOR SWITCH PACK – DRIVER
DD2
26-WAY / YELLOW
DRIVER DOOR ARM REST
DRIVER DOOR CONTROL MODULE
CA85
12-WAY / BLACK
DRIVER DOOR
DD4
26-WAY / NATURAL
DT2
20-WAY / BLACK
GENERAL ELECTRONIC CONTROL MODULE
FH9
22-WAY / BLACK
LH ‘A’ POST
CA24
26-WAY / NATURAL
CA31
20-WAY / BLACK
FH59
12-WAY / BLACK
FH60
17-WAY / BLACK
HEATED REAR WINDOW RELAY
—
—
REAR POWER DISTRIBUTION FUSE BOX – R1
HEATED REAR WINDOW
CA20
2-WAY / GREY
CONNECTOR LOCATED BELOW PARCEL SHELF, LH SIDE
INSTRUMENT CLUSTER
FC14
22-WAY / GREY
INSTRUMENT PANEL
FC15
20-WAY / BLACK
FC63
22-WAY / BLACK
REAR ELECTRONIC CONTROL MODULE
CA63
17-WAY / BLACK
LUGGAGE COMPARTMENT, RH REAR
CA100
12-WAY / BLACK
CA101
20-WAY / BLACK
CA102
22-WAY / BLACK
CA103
26-WAY / NATURAL
REAR POWER DISTRIBUTION FUSE BOX
—
—
LUGGAGE COMPARTMENT
HARNESS IN-LINE CONNECTORS
Connector
Connector Description / Location
Location
CA3A/B
14-WAY / GREY / CABIN HARNESS BRIDGE
LUGGAGE COMPARTMENT, LH REAR
DD8
16-WAY / BLUE / CABIN HARNESS TO DRIVER DOOR HARNESS
DRIVER DOOR
DT8
14-WAY / GREY / CABIN HARNESS TO DRIVER DOOR TRIM HARNESS
DRIVER DOOR
GROUNDS
Ground
Location
CA30
LH LOWER ‘A’ POST, ADJACENT TO THE GENERAL ELECTRONIC CONTROL MODULE (REARWARD OF FH77)
CA50
RH LOWER ‘A’ POST, BELOW PRIMARY JUNCTION FUSE BOX
CA156
LUGGAGE COMPARTMENT, RH SIDE
FH77
LH LOWER ‘A’ POST, ADJACENT TO THE GENERAL ELECTRONIC CONTROL MODULE (FORWARD OF CA30)
FOR CONTROL MODULE PIN-OUT INFORMATION, UNFOLD PAGE TO LEFT.
CONTROL MODULE PIN-OUT INFORMATION
Air Conditioning Control Module – Panel
Pin
Description and Characteristic
C
FC28-1
CAN -
C
FC28-12
CAN
Air Conditioning Control Module – Remote
Pin
Description and Characteristic
C
FC41-1
CAN -
C
FC41-12
CAN +
Driver Door Control Module
Pin
Description and Characteristic
S
CA85-3
SCP +
S
CA85-4
SCP -
PG
CA85-7
POWER GROUND: GROUND
PG
CA85-8
POWER GROUND: GROUND
B+
CA85-11
BATTERY POWER SUPPLY: B+
B+
CA85-12
SWITCHED SYSTEM POWER SUPPLY: B+
I
DD4-3
MIRROR MOVEMENT UP: GROUND WHEN ACTIVATED
O
DD4-7
MEMORY SET INDICATOR: TO ACTIVATE, DDCM SWITCHES CIRCUIT TO B+
I
DD4-10
MEMORY 1: GROUND WHEN SELECTED
I
DD4-11
MEMORY 2: GROUND WHEN SELECTED
I
DD4-19
MIRROR MOVEMENT RIGHT: GROUND WHEN ACTIVATED
I
DD4-20
MIRROR MOVEMENT DOWN: GROUND WHEN ACTIVATED
I
DD4-21
MIRROR MOVEMENT LEFT: GROUND WHEN ACTIVATED
I
DD4-23
LH DOOR MIRROR MOVEMENT SELECT: GROUND WHEN SELECTED
I
DD4-24
RH DOOR MIRROR MOVEMENT SELECT: GROUND WHEN SELECTED
I
DD4-25
MEMORY SET: GROUND WHEN SELECTED
O
DT2-1
DRIVER DOOR MIRROR LEFT: TO ACTIVATE, DDCM SWITCHES CIRCUIT TO B+
O
DT2-2
DRIVER DOOR MIRROR RIGHT: TO ACTIVATE, DDCM SWITCHES CIRCUIT TO B+
O
DT2-3
DRIVER DOOR MIRROR UP: TO ACTIVATE, DDCM SWITCHES CIRCUIT TO B+
O
DT2-4
DRIVER DOOR MIRROR DOWN: TO ACTIVATE, DDCM SWITCHES CIRCUIT TO B+
SS
DT2-5
DRIVER DOOR MIRROR POSITION SENSORS SIGNAL SUPPLY VOLTAGE: B+
I
DT2-14
DRIVER DOOR MIRROR LEFT / RIGHT POSITION FEEDBACK SIGNAL : VARIABLE VOLTAGE
I
DT2-15
DRIVER DOOR MIRROR UP / DOWN POSITION FEEDBACK SIGNAL : VARIABLE VOLTAGE
SG
DT2-19
DRIVER DOOR MIRROR POSITION SENSORS SIGNAL GROUND: GROUND
General Electronic Control Module
Pin
Description and Characteristic
I
CA24-7
PASSENGER DOOR MIRROR LEFT / RIGHT POSITION FEEDBACK SIGNAL : VARIABLE VOLTAGE
SS
CA24-8
PASSENGER DOOR MIRROR POSITION SENSORS SIGNAL SUPPLY VOLTAGE: B+
I
CA24-11
PASSENGER DOOR MIRROR UP / DOWN POSITION FEEDBACK : VARIABLE VOLTAGE
O
CA24-20
PASSENGER DOOR MIRROR UP: TO ACTIVATE, GECM SWITCHES CIRCUIT TO B+
O
CA24-21
PASSENGER DOOR MIRROR DOWN: TO ACTIVATE, GECM SWITCHES CIRCUIT TO B+
SG
CA24-22
PASSENGER DOOR MIRROR POSITION SENSORS SIGNAL GROUND: GROUND
O
CA24-23
PASSENGER DOOR MIRROR LEFT: TO ACTIVATE, DDCM SWITCHES CIRCUIT TO B+
O
CA24-24
PASSENGER DOOR MIRROR RIGHT: TO ACTIVATE, DDCM SWITCHES CIRCUIT TO B+
S
FH59-1
SCP -
S
FH59-7
SCP +
B+
FH60-1
SWITCHED SYSTEM POWER SUPPLY: B+
PG
FH60-11
POWER GROUND: GROUND
Instrument Cluster
Pin
Description and Characteristic
S
FC15-10
SCP –
C
FC15-18
CAN +
C
FC15-19
CAN –
S
FC15-20
SCP +
Rear Electronic Control Module
Pin
Description and Characteristic
B+
CA101-3
BATTERY POWER SUPPLY: B+
S
CA102-1
SCP +
S
CA102-2
SCP -
O
CA102-7
HEATED REAR WINDOW ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND
PG
CA102-12
POWER GROUND: GROUND
B+
CA103-13
SWITCHED SYSTEM POWER SUPPLY: B+
NOTE: Refer to the Appendix at the rear of this book for Network Messages.
