Refer to the front of this book for detailed information and illustrations regarding the location and identification of harnesses, relays, fuses, grounds, control
modules and control module pins.
DATE OF ISSUE: June 2002
Fig. 16.8
COMPONENTS
Component Connector(s) Connector Description Location
NAVIGATION CONTROL MODULE CA176 2-WAY / GREY LUGGAGE COMPARTMENT, LH REAR
CA257 26-WAY / NATURAL
CA258 20-WAY / BLACK
CA259 12-WAY / BLACK
RA5 FIBER OPTIC CONNECTOR
NAVIGATION GPS ANTENNA CA175 2-WAY / GREY PARCEL SHELF, CENTER
NAVIGATION SCREEN AND TELEMATICS DISPLAY FC92 22-WAY / BLACK CENTER CONSOLE
FC102 2-WAY GREY
FC103 2-WAY GREY
FC104 2-WAY GREY
FC105 2-WAY GREY
OOF CONSOLE CA250 22-WAY / BLACK ROOF HEADLINER
TV ANTENNA AND AMPLIFIER 1 CA198 2-WAY / GREY PARCEL SHELF
TV ANTENNA AND AMPLIFIER 2 CA200 2-WAY / GREY PARCEL SHELF
TV ANTENNA AND AMPLIFIER 3 CA202 2-WAY / GREY PARCEL SHELF
TV ANTENNA AND AMPLIFIER 4 CA204 2-WAY / GREY PARCEL SHELF
VEHICLE INFORMATION ANTENNA CA208 ANTENNA CONNECTOR PARCEL SHELF
VEHICLE INFORMATION CONTROL MODULE CA207 ANTENNA CONNECTOR LUGGAGE COMPARTMENT, LH SIDE
CA268 ANTENNA CONNECTOR
CA273 10-WAY / BLACK
VEHICLE INFORMATION SENSOR FC95 ANTENNA CONNECTOR INSTRUMENT PANEL
HARNESS IN-LINE CONNECTORS
Connector Connector Description / Location Location
FC19 16-WAY / GREEN / CABIN HARNESS TO FASCIA HARNESS BEHIND INSTRUMENT PANEL, LH SIDE
FC93 2-WAY / BLACK / FASCIA HARNESS (ANTENNA) TO CABIN HARNESS (ANTENNA) BEHIND INSTRUMENT PANEL
FC98 4-WAY / BLACK / FASCIA HARNESS (ANTENNA) TO CABIN HARNESS (ANTENNA) BEHIND INSTRUMENT PANEL, LH SIDE
FC99 4-WAY / BLACK / FASCIA HARNESS (ANTENNA) TO CABIN HARNESS (ANTENNA) BEHIND INSTRUMENT PANEL, RH SIDE
FC122 6-WAY / BLACK / FASCIA HARNESS TO SEAT HARNESSES UNDER CENTER CONSOLE
GROUNDS
Ground Location
CA157 LUGGAGE COMPARTMENT, LH SIDE AFT OF WHEEL ARCH
FC38 UNDER CENTER OF INSTRUMENT PANEL, ON TRANSMISSION TUNNEL
