The following abbreviations are used to represent values for Control Module Pin-Out data
I Input PG Power Ground C CAN Network D Serial and Encoded Data
O Output SS Sensor / Signal Supply V S SCP Network V Voltage (DC)
B+ Battery Voltage SG Sensor / Signal Ground D2 D2B Network PWM Pulse Width Modulated
CAUTION: The information on this data page is furnished to aid the user in understanding circuit oper ation. THIS INFORMATION SHOULD BE USED FOR
REFERENCE ONLY.
NOTE: The values listed are approximately those that can be expected at the control module connector pins with all circuit connections made and all components
connected and fitted. Refer to the front of this book for detailed information and illustrations regarding the location and identification of harnesses, relays, fuses, grounds, control
modules and control module pins.
DATE OF ISSUE: June 2002
Fig. 08.4
COMPONENTS
Component Connector(s) Connector Description Location
BATTERY — — LUGGAGE COMPARTMENT
HIGH-MOUNTED STOP LAMP CA18 3-WAY / GREY PARCEL SHELF, CENTER
LICENSE PLATE LAMPS CA66 4-WAY / BLACK LUGGAGE COMPARTMENT LID
CA67 2-WAY / BLACK
REAR ELECTRONIC CONTROL MODULE CA63 17-WAY / BLACK LUGGAGE COMPARTMENT, RH REAR
CA100 12-WAY / BLACK
CA101 20-WAY / BLACK
CA102 22-WAY / BLACK
CA103 26-WAY / NATURAL
TAIL LAMP UNIT – LH CA10 7-WAY / BLACK LUGGAGE COMPARTMENT, LH REAR
TAIL LAMP UNIT – RH CA68 7-WAY / BLACK LUGGAGE COMPARTMENT, RH REAR
TRAILER TOWING CONNECTOR TJ2 NOT AVAILABLE LUGGAGE COMPARTMENT
TRAILER TOWING CONNECTORS TJ3 NOT AVAILABLE LUGGAGE COMPARTMENT
TJ4 NOT AVAILABLE
TRAILER TOWING CONTROL MODULE TT7 NOT AVAILABLE LUGGAGE COMPARTMENT
TT8 NOT AVAILABLE
TRAILER TOWING JUNCTION BOX TT5 NOT AVAILABLE LUGGAGE COMPARTMENT
TRAILER TOWING RELAY TT6 RELAY CONNECTOR LUGGAGE COMPARTMENT
HARNESS IN-LINE CONNECTORS
Connector Connector Description / Location Location
BR1 10-WAY / GREY / CABIN HARNESS TO REAR BUMPER HARNESS BEHIND REAR BUMPER, RH SIDE
TT1 6-WAY / GREY / TRAILER TOWING IN-LINE CONNECTOR LUGGAGE COMPARTMENT, ADJACENT TO RH TAIL LAMP
GROUNDS
Ground Location
CA116 BEHIND REAR SEAT BACK, RH SIDE
JB1 LUGGAGE COMPARTMENT, BATTERY GROUND
TT4 NOT AVAILABLE
FOR CONTROL MODULE PIN-OUT INFORMATION, UNFOLD PAGE TO LEFT.
CONTROL MODULE PIN-OUT INFORMATION
Rear Electronic Control Module
Pin Description and Characteristic
O CA100-5 LICENSE PLATE LAMPS ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND
O TT2-1 RH STOP LAMP ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND
O TT2-2 LH STOP LAMP ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND
O TT2-3 LH REAR TURN SIGNAL ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND (PULSED)
O TT2-4 RH REAR TURN SIGNAL ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND (PULSED)
O TT2-5 RH TAIL LAMPS ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND
O TT2-6 LH TAIL LAMPS ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND
O TT2-9 LH REVERSE LAMP ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND
O TT2-10 RH REVERSE LAMP ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND
O TT2-17 HIGH-MOUNTED STOP LAMP ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND
