Refer to the front of this book for detailed information and illustrations regarding the location and identification of harnesses, relays, fuses, grounds, control
modules and control module pins.
DATE OF ISSUE: June 2002
Fig. 11.3
COMPONENTS
Component Connector(s) Connector Description Location
LUMBAR PUMP – DRIVER DL4 3-WAY / BLACK LOWER SEAT BACK
SEAT MOTORS AND POSITION SENSORS – DRIVER DM25 4-WAY / BLACK DRIVER SEAT
DM26 4-WAY / BLACK
DM27 4-WAY / BLACK
DM28 4-WAY / BLACK
SEAT SWITCH PACK – DRIVER DM7 12-WAY / BLACK DRIVER SEAT
DM43 14-WAY / BLACK
HARNESS IN-LINE CONNECTORS
Connector Connector Description / Location Location
DL2 6-WAY / BLACK / DRIVER SEAT IN-LINE CONNECTOR DRIVER SEAT BACK REST
DM22 4-WAY / GREY / CABIN HARNESS TO DRIVER SEAT HARNESS UNDER DRIVER SEAT
DM23 20-WAY / BLACK / CABIN HARNESS TO DRIVER SEAT HARNESS UNDER DRIVER SEAT
GROUNDS
Ground Location
CA141 UNDER LH FRONT SEAT
CA154 UNDER RH FRONT SEAT
