The following abbreviations are used to represent values for Control Module Pin-Out data
I Input PG Power Ground C CAN Network D Serial and Encoded Data
O Output SS Sensor / Signal Supply V S SCP Network V Voltage (DC)
B+ Battery Voltage SG Sensor / Signal Ground D2 D2B Network PWM Pulse Width Modulated
CAUTION: The information on this data page is furnished to aid the user in understanding circuit oper ation. THIS INFORMATION SHOULD BE USED FOR
REFERENCE ONLY.
NOTE: The values listed are approximately those that can be expected at the control module connector pins with all circuit connections made and all components
connected and fitted. Refer to the front of this book for detailed information and illustrations regarding the location and identification of harnesses, relays, fuses, grounds, control
modules and control module pins.
DATE OF ISSUE: June 2002
Fig. 09.1
COMPONENTS
Component Connector(s) Connector Description Location
COURTESY LAMP – DRIVER DOOR DD6 2-WAY BLACK DRIVER DOOR CASING
COURTESY LAMP – PASSENGER DOOR PD3 2-WAY BLACK PASSENGER DOOR CASING
DOOR LATCH ASSEMBLY – DRIVER DT5 10-WAY / BLACK DRIVER DOOR
DOOR LATCH ASSEMBLY – PASSENGER PT3 10-WAY / BLACK PASSENGER DOOR
DOOR LATCH ASSEMBLY – LH REAR CA81 10-WAY / BLACK LH REAR DOOR
DOOR LATCH ASSEMBLY – RH REAR CA90 10-WAY / BLACK RH REAR DOOR
DRIVER DOOR CONTROL MODULE CA85 12-WAY / BLACK DRIVER DOOR
DD4 26-WAY / NATURAL
DT2 20-WAY / BLACK
FASCIA LAMP – LH FC44 2-WAY / WHITE INSTRUMENT PANEL, LH SIDE
FASCIA LAMP – RH FC51 2-WAY / WHITE INSTRUMENT PANEL, RH SIDE
GENERAL ELECTRONIC CONTROL MODULE FH9 22-WAY / BLACK LH ‘A’ POST
CA24 26-WAY / NATURAL
CA31 20-WAY / BLACK
FH59 12-WAY / BLACK
FH60 17-WAY / BLACK
GLOVE BOX LAMP GL1 2-WAY / BLACK GLOVE BOX
INSTRUMENT CLUSTER FC14 22-WAY / GREY INSTRUMENT PANEL
FC15 20-WAY / BLACK
FC63 22-WAY / BLACK
MAP LAMP – LH REAR RF20 3-WAY / BLACK LH REAR ASSIST HANDLE
MAP LAMP – RH REAR RF23 3-WAY / BLACK RH REAR ASSIST HANDLE
REAR ELECTRONIC CONTROL MODULE CA63 17-WAY / BLACK LUGGAGE COMPARTMENT, RH REAR
CA100 12-WAY / BLACK
CA101 20-WAY / BLACK
CA102 22-WAY / BLACK
CA103 26-WAY / NATURAL
ROOF CONSOLE CA250 22-WAY / BLACK ROOF HEADLINER
SUN VISOR LAMP – LH RF12 2-WAY / BLACK LH SUN VISOR
SUN VISOR LAMP – RH RF24 2-WAY / BLACK RH SUN VISOR
TRUNK AJAR SWITCH CA117 2-WAY / BLACK LUGGAGE COMPARTMENT LID
TRUNK LAMP – LH CA96 2-WAY / BLACK LUGGAGE COMPARTMENT, LH SIDE
TRUNK LID LAMP CA167 2-WAY / BLACK LUGGAGE COMPARTMENT LID
HARNESS IN-LINE CONNECTORS
Connector Connector Description / Location Location
CA3A/B 14-WAY / GREY / CABIN HARNESS BRIDGE LUGGAGE COMPARTMENT, LH REAR
DD8 16-WAY / BLUE / CABIN HARNESS TO DRIVER DOOR HARNESS DRIVER DOOR
DT8 14-WAY / GREY / CABIN HARNESS TO DRIVER DOOR TRIM HARNESS DRIVER DOOR
FC23 10-WAY / GREY / CABIN HARNESS TO FASCIA HARNESS BEHIND INSTRUMENT PANEL, LH SIDE
FC33 16-WAY / GREEN / CABIN HARNESS TO FASCIA HARNESS BEHIND INSTRUMENT PANEL, RH SIDE
FC117 10-WAY / BLACK / STEERING WHEEL CASSETTE STEERING COLUMN
PD4 10-WAY / GREY / CABIN HARNESS TO PASSENGER DOOR HARNESS PASSENGER DOOR
PT1 14-WAY / GREY / CABIN HARNESS TO PASSENGER DOOR TRIM HARNESS PASSENGER DOOR
RF34 16-WAY / GREEN / CABIN HARNESS TO DOOR HARNESS ‘D’ POST, UNDER PARCEL SHELF
GROUNDS
Ground Location
CA30 LH LOWER ‘A’ POST, ADJACENT TO THE GENERAL ELECTRONIC CONTROL MODULE (REARWARD OF FH77)
CA50 RH LOWER ‘A’ POST, BELOW PRIMARY JUNCTION FUSE BOX
CA116 BEHIND REAR SEAT BACK, RH SIDE
CA141 UNDER LH FRONT SEAT
CA154 UNDER RH FRONT SEAT
CA156 LUGGAGE COMPARTMENT, RH SIDE
FC38 UNDER CENTER OF INSTRUMENT PANEL, ON TRANSMISSION TUNNEL
FH77 LH LOWER ‘A’ POST, ADJACENT TO THE GENERAL ELECTRONIC CONTROL MODULE (FORWARD OF CA30)
FOR CONTROL MODULE PIN-OUT INFORMATION, UNFOLD PAGE TO LEFT.
CONTROL MODULE PIN-OUT INFORMATION
Driver Door Control Module
Pin Description and Characteristic
S CA85-3 SCP +
S CA85-4 SCP -
PG CA85-8 POWER GROUND: GROUND
B+ CA85-11 BATTERY POWER SUPPLY: B+
I DT2-16 DRIVER DOOR ALARM SET / LOCK SWITCH (NORMALLY OPEN): OPEN CIRCUIT / GROUND
I DT2-17 DRIVER DOOR ALARM RESET / UNLOCK SWITCH (NORMALLY OPEN): OPEN CIRCUIT / GROUND
General Electronic Control Module
Pin Description and Characteristic
I CA24-15 PASSENGER DOOR AJAR SWITCH (NORMALLY OPEN): OPEN CIRCUIT / GROUND
I CA31-8 DRIVER DOOR AJAR SWITCH (NORMALLY OPEN): OPEN CIRCUIT / GROUND
– CA31-12 INTERIOR LIGHTING ACTIVATE: TO ACTIVATE, GECM SWITCHES CIRCUIT TO GROUND (PWM)
S FH59-1 SCP -
B+ FH59-6 BATTERY POWER SUPPLY (LOGIC): B+
S FH59-7 SCP +
PG FH60-11 POWER GROUND: GROUND
Instrument Cluster
Pin Description and Characteristic
SG FC14-13 ROOF CONSOLE COURTESY LAMP SWITCH GROUND: SWITCH OPEN = GROUND
SG FC14-14 SIGNAL GROUND: GROUND
PG FC15-2 POWER GROUND: GROUND
B+ FC15-3 BATTERY POWER SUPPLY (LOGIC): B+
S FC15-10 SCP –
S FC15-20 SCP +
Rear Electronic Control Module
Pin Description and Characteristic
O CA100-11 TRUNK LAMPS ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND
B+ CA101-3 BATTERY POWER SUPPLY: B+
I CA101-17 LHD – RH REAR DOOR AJAR SWITCH (NORMALLY OPEN): OPEN CIRCUIT / GROUND
RHD – LH REAR DOOR AJAR SWITCH (NORMALLY OPEN): OPEN CIRCUIT / GROUND
S CA102-1 SCP +
S CA102-2 SCP -
PG CA102-12 POWER GROUND: GROUND
I CA102-14 TRUNK AJAR SWITCH (NORMALLY OPEN): OPEN CIRCUIT / GROUND
I CA103-16 LHD – LH REAR DOOR AJAR SWITCH (NORMALLY OPEN): OPEN CIRCUIT / GROUND
RHD – RH REAR DOOR AJAR SWITCH (NORMALLY OPEN): OPEN CIRCUIT / GROUND
NOTE: Refer to the Appendix at the rear of this book for Network Messages.
