The following abbreviations are used to represent values for Control Module Pin-Out data
I Input PG Power Ground C CAN Network D Serial and Encoded Data
O Output SS Sensor / Signal Supply V S SCP Network V Voltage (DC)
B+ Battery Voltage SG Sensor / Signal Ground D2 D2B Network PWM Pulse Width Modulated
CAUTION: The information on this data page is furnished to aid the user in understanding circuit oper ation. THIS INFORMATION SHOULD BE USED FOR
REFERENCE ONLY.
NOTE: The values listed are approximately those that can be expected at the control module connector pins with all circuit connections made and all components
connected and fitted. Refer to the front of this book for detailed information and illustrations regarding the location and identification of harnesses, relays, fuses, grounds, control
modules and control module pins.
DATE OF ISSUE: June 2002
Fig. 08.3
COMPONENTS
Component Connector(s) Connector Description Location
AUXILIARY LIGHTING SWITCH FC11 10-WAY / YELLOW FASCIA, ADJACENT TO STEERING COLUMN
BRAKE ON / OFF SWITCH CA37 2-WAY / GREEN TOP OF BRAKE PEDAL
CENTER CONSOLE SWITCH PACK FC113 8-WAY / BLACK CENTER CONSOLE
FC119 8-WAY / BLACK
DUAL SOLAR SENSOR (AUTO HEADLAMP) SL1 6-WAY / BLACK INSTRUMENT PANEL GLARE SHIELD, FRONT CENTER
HIGH-MOUNTED STOP LAMP CA18 3-WAY / GREY PARCEL SHELF, CENTER
INSTRUMENT CLUSTER FC14 22-WAY / GREY INSTRUMENT PANEL
FC15 20-WAY / BLACK
FC63 22-WAY / BLACK
LICENSE PLATE LAMPS CA66 4-WAY / BLACK LUGGAGE COMPARTMENT LID
CA67 2-WAY / BLACK
MAIN LIGHTING SWITCH (COLUMN SWITCHGEAR) FC116 6-WAY / BLACK STEERING COLUMN COWLING
REAR ELECTRONIC CONTROL MODULE CA63 17-WAY / BLACK LUGGAGE COMPARTMENT, RH REAR
CA100 12-WAY / BLACK
CA101 20-WAY / BLACK
CA102 22-WAY / BLACK
CA103 26-WAY / NATURAL
REVERSE SWITCH GB5 2-WAY / BLACK TRANSMISSION, LH REAR
SIDE MARKER LAMP – LH BR6 2-WAY / BLACK REAR BUMPER, LH SIDE
SIDE MARKER LAMP – RH BR7 2-WAY / BLACK REAR BUMPER, RH SIDE
TAIL LAMP UNIT – LH CA10 7-WAY / BLACK LUGGAGE COMPARTMENT, LH REAR
TAIL LAMP UNIT – RH CA68 7-WAY / BLACK LUGGAGE COMPARTMENT, RH REAR
HARNESS IN-LINE CONNECTORS
Connector Connector Description / Location Location
BR1 10-WAY / GREY / CABIN HARNESS TO REAR BUMPER HARNESS BEHIND REAR BUMPER, RH SIDE
FC12 14-WAY / GREY / FASCIA HARNESS TO FRONT HARNESS BEHIND INSTRUMENT PANEL, PASSENGER SIDE
GB1 16-WAY / GREY / ENGINE HARNESS TO TRANSMISSION HARNESS ADJACENT TO TRANSMISSION BELL HOUSING
PI41 42-WAY / BLACK / ENGINE HARNESS TO VEHICLE HARNESSES ENGINE COMPARTMENT, BULKHEAD, PASSENGER SIDE
SL3 10-WAY / GREY / FASCIA HARNESS TO SOLAR SENSOR LINK BEHIND INSTRUMENT PANEL, RH SIDE
GROUNDS
Ground Location
CA116 BEHIND REAR SEAT BACK, RH SIDE
CA156 LUGGAGE COMPARTMENT, RH SIDE
FC38 UNDER CENTER OF INSTRUMENT PANEL, ON TRANSMISSION TUNNEL
PI40 (LHD) ENGINE COMPARTMENT, BEHIND RH WHEEL ARCH LINER
PI40 (RHD) ENGINE COMPARTMENT, BEHIND LH WHEEL ARCH LINER
FOR CONTROL MODULE PIN-OUT INFORMATION, UNFOLD PAGE TO LEFT.
CONTROL MODULE PIN-OUT INFORMATION
Instrument Cluster
Pin Description and Characteristic
O FC14-9 HAZARD INDICATOR: PULSED B+
I FC14-11 REVERSE SWITCH SIGNAL: REVERSE = GROUND
SG FC14-14 SIGNAL GROUND: GROUND
PG FC15-2 POWER GROUND: GROUND
B+ FC15-3 BATTERY POWER SUPPLY (LOGIC): B+
S FC15-10 SCP –
S FC15-20 SCP +
I FC63-1 MAIN LIGHTING SWITCH SIGNALS – TURN SIGNALS, HAZARD WARNING: TURN = VARIABLE RESISTANCE; HAZARD = GROUND
I FC63-2 MAIN LIGHTING SWITCH SIGNALS – EXIT DELAY: VARIABLE RESISTANCE
SG FC63-3 MAIN LIGHTING SWITCH SIGNAL GROUND: GROUND
I FC63-6 FOG LAMPS SWITCH SIGNAL: VARIABLE RESISTANCE
SG FC63-10 AUTOLAMP SENSOR GROUND: GROUND
I FC63-12 MAIN LIGHTING SWITCH SIGNALS – MAIN, FLASH: VARIABLE RESISTANCE
I FC63-13 MAIN LIGHTING SWITCH SIGNALS – OFF, SIDE, DIP, AUTOLAMP: VARIABLE RESISTANCE
SG FC63-15 AUXILIARY LIGHTING SWITCH SIGNAL GROUND: GROUND
I FC63-21 AUTOLAMP SENSOR SIGNAL: VARIABLE RESISTANCE
Rear Electronic Control Module
Pin Description and Characteristic
O CA63-1 RH STOP LAMP ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND
O CA63-2 LH STOP LAMP ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND
O CA63-3 LH REAR TURN SIGNAL ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND (PULSED)
O CA63-4 RH REAR TURN SIGNAL ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND (PULSED)
O CA63-5 RH TAIL LAMPS ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND
O CA63-6 LH TAIL LAMPS ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND
O CA63-7 LH REAR FOG LAMP ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND
O CA63-8 RH REAR FOG LAMP ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND
O CA63-9 LH REVERSE LAMP ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND
O CA63-10 RH REVERSE LAMP ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND
O CA63-17 HIGH-MOUNTED STOP LAMP ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND
O CA100-5 LICENSE PLATE LAMPS ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND
O CA100-6 LH REAR SIDE MARKER LAMP ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND
O CA100-12 RH REAR SIDE MARKER LAMP ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND
B+ CA101-3 BATTERY POWER SUPPLY: B+
S CA102-1 SCP +
S CA102-2 SCP -
PG CA102-12 POWER GROUND: GROUND
I CA102-13 BRAKE ON / OFF SWITCH (NORMALLY OPEN): OPEN CIRCUIT / B+
PG CA103-11 POWER GROUND: GROUND
PG CA103-12 POWER GROUND: GROUND
PG CA103-25 POWER GROUND: GROUND
PG CA103-26 POWER GROUND: GROUND
NOTE: Refer to the Appendix at the rear of this book for Network Messages.
