Refer to the front of this book for detailed information and illustrations regarding the location and identification of harnesses, relays, fuses, grounds, control
modules and control module pins.
DATE OF ISSUE: June 2002
Fig. 20.3
COMPONENTS
Component Connector(s) Connector Description Location
AUDIO UNIT FC94 20-WAY / BLACK CENTER CONSOLE
FC96 ANTENNA CONNECTOR
FC108 FIBER OPTIC CONNECTOR
CD AUTOCHANGER CA267 3-WAY / BLACK LUGGAGE COMPARTMENT, LH REAR
RA2 FIBER OPTIC CONNECTOR
CELLULAR PHONE CONTROL MODULE CA209 2-WAY / BLACK LUGGAGE COMPARTMENT, LH REAR
CA210 2-WAY / BLACK
CA211 2-WAY / BLACK
CA261 32-WAY / BLACK
RA3 FIBER OPTIC CONNECTOR
NAVIGATION CONTROL MODULE CA176 2-WAY / GREY LUGGAGE COMPARTMENT, LH REAR
CA257 26-WAY / NATURAL
CA258 20-WAY / BLACK
CA259 12-WAY / BLACK
RA5 FIBER OPTIC CONNECTOR
POWER AMPLIFIER CA263 POWER AMPLIFIER CONNECTOR LUGGAGE COMPARTMENT, LH REAR
CA264 POWER AMPLIFIER CONNECTOR
RA6 FIBER OPTIC CONNECTOR
VOICE ACTIVATION CONTROL MODULE CA300 22-WAY / GREY LUGGAGE COMPARTMENT, LH REAR
RA4 FIBER OPTIC CONNECTOR
HARNESS IN-LINE CONNECTORS
Connector Connector Description / Location Location
FC107 2-WAY / BLACK / FIBER OPTIC IN-LINE CONNECTOR UNDER CENTER CONSOLE
FC23 10-WAY / GREY / CABIN HARNESS TO FASCIA HARNESS BEHIND INSTRUMENT PANEL, LH SIDE
RA1 2-WAY / FIBER OPTIC / FIBER OPTIC IN-LINE CONNECTOR LUGGAGE COMPARTMENT, LH SIDE
