The following abbreviations are used to represent values for Control Module Pin-Out data
I
Input
PG
Power Ground
C
CAN Network
D
Serial and Encoded Data
O
Output
SS
Sensor / Signal Supply V
S
SCP Network
V
Voltage (DC)
B+
Battery Voltage
SG
Sensor / Signal Ground
D2
D2B Network
PWM Pulse Width Modulated
CAUTION: The information on this data page is furnished to aid the user in understanding circuit oper ation. THIS INFORMATION SHOULD BE USED FOR
REFERENCE ONLY.
NOTE: The values listed are approximately those that can be expected at the control module connector pins with all circuit connections made and all components
connected and fitted.
Refer to the front of this book for detailed information and illustrations regarding the location and identification of harnesses, relays, fuses, grounds, control
modules and control module pins.
DATE OF ISSUE: June 2002
Fig. 08.2
COMPONENTS
Component
Connector(s)
Connector Description
Location
AUXILIARY LIGHTING SWITCH
FC11
10-WAY / YELLOW
FASCIA, ADJACENT TO STEERING COLUMN
CENTER CONSOLE SWITCH PACK
FC113
8-WAY / BLACK
CENTER CONSOLE
FC119
8-WAY / BLACK
DUAL SOLAR SENSOR (AUTO HEADLAMP)
SL1
6-WAY / BLACK
INSTRUMENT PANEL GLARE SHIELD, FRONT CENTER
FRONT FOG LAMP – LH
BF4
2-WAY / BLACK
FRONT BUMPER, LH SIDE
BF6
2-WAY / BLACK
FRONT FOG LAMP – RH
BF5
2-WAY / BLACK
FRONT BUMPER, RH SIDE
BF7
2-WAY / BLACK
FRONT FOG LAMP RELAY
—
—
FRONT POWER DISTRIBUTION FUSE BOX – R11
FRONT POWER DISTRIBUTION FUSE BOX
—
—
ENGINE COMPARTMENT, RH SIDE
GENERAL ELECTRONIC CONTROL MODULE
FH9
22-WAY / BLACK
LH ‘A’ POST
CA24
26-WAY / NATURAL
CA31
20-WAY / BLACK
FH59
12-WAY / BLACK
FH60
17-WAY / BLACK
HEADLAMP UNIT – LH
HL2
2-WAY / BLACK
ENGINE COMPARTMENT, LH FRONT
HL3
2-WAY / BLACK
HL4
2-WAY / BLACK
HL6 (HID)
2-WAY / WHITE
HL7
3-WAY / GREY
HL8
2-WAY / BLACK
HEADLAMP UNIT – RH
HR2
2-WAY / BLACK
ENGINE COMPARTMENT, RH FRONT
HR3
2-WAY / BLACK
HR4
2-WAY / BLACK
HR6 (HID)
2-WAY / WHITE
HR7
3-WAY / GREY
HR8
2-WAY / BLACK
HID RELAY – LH
—
—
FRONT POWER DISTRIBUTION FUSE BOX – R10
HID RELAY – RH
—
—
FRONT POWER DISTRIBUTION FUSE BOX – R13
INSTRUMENT CLUSTER
FC14
22-WAY / GREY
INSTRUMENT PANEL
FC15
20-WAY / BLACK
FC63
22-WAY / BLACK
MAIN LIGHTING SWITCH (COLUMN SWITCHGEAR)
FC116
6-WAY / BLACK
STEERING COLUMN COWLING
SIDE MARKER – LH
BF2
2-WAY / BLACK
FRONT BUMPER, LH SIDE
SIDE MARKER – RH
BF3
2-WAY / BLACK
FRONT BUMPER, RH SIDE
TURN REPEATER – LH
FH62
2-WAY / BLACK
LH FRONT FENDER
TURN REPEATER – RH
FH76
2-WAY / BLACK
RH FRONT FENDER
HARNESS IN-LINE CONNECTORS
Connector
Connector Description / Location
Location
BF1
6-WAY / GREY / FRONT HARNESS TO FRONT BUMPER HARNESS
BEHIND FRONT BUMPER, LH SIDE
FH6
16-WAY GREEN / CABIN HARNESS TO FRONT HARNESS
LH ‘A’ POST, ADJACENT TO GECM
FH39
12-WAY / GREY / FRONT HARNESS TO RH FRONT HEADLAMP LINK
BEHIND FRONT BUMPER, RH SIDE
FH40
12-WAY / GREY / FRONT HARNESS TO LH FRONT HEADLAMP LINK
BEHIND FRONT BUMPER, LH SIDE
SL3
10-WAY / GREY / FASCIA HARNESS TO SOLAR SENSOR LINK
BEHIND INSTRUMENT PANEL, RH SIDE
GROUNDS
Ground
Location
FC38
UNDER CENTER OF INSTRUMENT PANEL, ON TRANSMISSION TUNNEL
FH22
ENGINE COMPARTMENT, BEHIND LH HEADLAMP
FH42
ENGINE COMPARTMENT, BEHIND RH HEADLAMP
FH77
LH LOWER ‘A’ POST, ADJACENT TO THE GENERAL ELECTRONIC CONTROL MODULE (FORWARD OF CA30)
FOR CONTROL MODULE PIN-OUT INFORMATION, UNFOLD PAGE TO LEFT.
CONTROL MODULE PIN-OUT INFORMATION
General Electronic Control Module
Pin
Description and Characteristic
O
CA31-20
LH HID RELAY ACTIVATE: TO ACTIVATE, GECM SWITCHES CIRCUIT TO GROUND†
O
FH9-6
RH HID RELAY ACTIVATE: TO ACTIVATE, GECM SWITCHES CIRCUIT TO GROUND
O
FH9-7
LH TURN SIGNAL REPEATER LAMP ACTIVATE: TO ACTIVATE, GECM SWITCHES CIRCUIT TO GROUND (PULSED)
O
FH9-11
RH SIDE MARKER LAMP ACTIVATE: TO ACTIVATE, GECM SWITCHES CIRCUIT TO GROUND
O
FH9-19
RH TURN SIGNAL REPEATER LAMP ACTIVATE: TO ACTIVATE, GECM SWITCHES CIRCUIT TO GROUND (PULSED)
O
FH9-22
LH SIDE MARKER LAMP ACTIVATE: TO ACTIVATE, GECM SWITCHES CIRCUIT TO GROUND†
S
FH59-1
SCP -
O
FH59-2
LH FRONT SIDE LAMP ACTIVATE: TO ACTIVATE, GECM SWITCHES CIRCUIT TO GROUND
O
FH59-5
FRONT FOG LAMP RELAY ACTIVATE: TO ACTIVATE, GECM SWITCHES CIRCUIT TO GROUND
B+
FH59-6
BATTERY POWER SUPPLY (LOGIC): B+
S
FH59-7
SCP +
O
FH59-10
RH FRONT SIDE LAMP ACTIVATE: TO ACTIVATE, GECM SWITCHES CIRCUIT TO GROUND
PG
FH59-12
POWER GROUND: GROUND
O
FH60-4
RH FRONT TURN SIGNAL ACTIVATE: TO ACTIVATE, GECM SWITCHES CIRCUIT TO GROUND (PULSED)
O
FH60-5
LH FRONT TURN SIGNAL ACTIVATE: TO ACTIVATE, GECM SWITCHES CIRCUIT TO GROUND (PULSED)
O
FH60-10
RH MAIN BEAM ACTIVATE: TO ACTIVATE, GECM SWITCHES CIRCUIT TO GROUND
PG
FH60-11
POWER GROUND: GROUND
PG
FH60-13
POWER GROUND: GROUND
PG
FH60-14
POWER GROUND: GROUND
PG
FH60-15
POWER GROUND: GROUND
O
FH60-17
LH MAIN BEAM ACTIVATE: TO ACTIVATE, GECM SWITCHES CIRCUIT TO GROUND
Instrument Cluster
Pin
Description and Characteristic
O
FC14-9
HAZARD INDICATOR: PULSED B+
SG
FC14-14
SIGNAL GROUND: GROUND
PG
FC15-2
POWER GROUND: GROUND
B+
FC15-3
BATTERY POWER SUPPLY (LOGIC): B+
S
FC15-10
SCP –
S
FC15-20
SCP +
I
FC63-1
MAIN LIGHTING SWITCH SIGNALS – TURN SIGNALS, HAZARD WARNING: TURN = VARIABLE RESISTANCE; HAZARD = GROUND
I
FC63-2
MAIN LIGHTING SWITCH SIGNALS – EXIT DELAY: VARIABLE RESISTANCE
SG
FC63-3
MAIN LIGHTING SWITCH SIGNAL GROUND: GROUND
I
FC63-6
FOG LAMPS SWITCH SIGNAL: VARIABLE RESISTANCE
SG
FC63-10
AUTOLAMP SENSOR GROUND: GROUND
I
FC63-12
MAIN LIGHTING SWITCH SIGNALS – MAIN, FLASH: VARIABLE RESISTANCE
I
FC63-13
MAIN LIGHTING SWITCH SIGNALS – OFF, SIDE, DIP, AUTOLAMP: VARIABLE RESISTANCE
SG
FC63-15
AUXILIARY LIGHTING SWITCH SIGNAL GROUND: GROUND
I
FC63-21
AUTOLAMP SENSOR SIGNAL: VARIABLE RESISTANCE
NOTE: Refer to the Appendix at the rear of this book for Network Messages.
