Jaguar S-TYPE 2002.5
13
DATE OF ISSUE: June 2002
Symbols and Codes
Wiring Color Codes
N
Brown
O
Orange
B
Black
S
Slate
W
White
L
Light
K
Pink
U
Blue
G
Green
P
Purple
R
Red
BRD
Braid
Y
Yellow
BOF
Black fiber optic (D2B Network)
Code Numbering
When numbering connectors, grounds and splices, Jaguar Engineer-
ing uses a three-position format: CA001, CA002, etc. Because space
is limited in this Electrical Guide the codes have, in most cases, been
shortened. Thus CA001-001 becomes CA1-1, CA002-001 becomes
CA2-1, etc.
Harness Codes
AC
Climate Control Link
AT
Alarm Link
BF
Front Bumper Harness
BR
Rear Bumper Harness
CA
Cabin Harness
CP
Intercooler Pump Link
CV
Canister Vent Link
DD
Driver Door Harness
DM
Driver Memory Seat Harness
DT
Driver Door Trim Link
FC
Fascia Harness
FH
Front Harness
FL
LH Front Headlamp Link
FP
Fuel Pump Harness
FR
RH Front Headlamp Link
GB
Transmission Harness
IL
Fuel Injector Link
PD
Passenger Door
PI
Engine Harness
PN
Passenger Seat Harness
PT
Passenger Door Trim Link
RA
D2B Network Harness
RF
Roof Harness
SL
Solar Sensor Link
SR
Sliding Roof Harness
SW
Subwoofer Link
TT
Trailer Tow Harness
