Refer to the front of this book for detailed information and illustrations regarding the location and identification of harnesses, relays, fuses, grounds, control
modules and control module pins.
DATE OF ISSUE: June 2002
Fig. 11.6
COMPONENTS
Component Connector(s) Connector Description Location
CENTER CONSOLE SWITCH PACK FC113 8-WAY / BLACK CENTER CONSOLE
FC119 8-WAY / BLACK
SEAT BACK HEATER – DRIVER DB7 2-WAY / BLACK DRIVER SEAT BACK
SEAT BACK HEATER – PASSENGER PB7 2-WAY / BLACK PASSENGER SEAT BACK
SEAT CUSHION HEATER – DRIVER DM16 4-WAY / BLACK DRIVER SEAT CUSHION
SEAT CUSHION HEATER – PASSENGER PN12 4-WAY / BLACK PASSENGER SEAT CUSHION
SEAT HEATER MODULE – DRIVER DM15 12-WAY / GREY UNDER DRIVER SEAT
SEAT HEATER MODULE – PASSENGER PN7 12-WAY / GREY UNDER PASSENGER SEAT
HARNESS IN-LINE CONNECTORS
Connector Connector Description / Location Location
DM23 20-WAY / BLACK / CABIN HARNESS TO DRIVER SEAT HARNESS UNDER DRIVER SEAT
FC17 16-WAY / BLUE / CABIN HARNESS TO FASCIA HARNESS BEHIND INSTRUMENT PANEL, PASSENGER SIDE
FC26 16-WAY / BLUE / CABIN HARNESS TO FASCIA HARNESS BEHIND INSTRUMENT PANEL, DRIVER SIDE
PN24 20-WAY / BLACK / CABIN HARNESS TO PASSENGER SEAT HARNESS UNDER PASSENGER SEAT
GROUNDS
Ground Location
CA141 UNDER LH FRONT SEAT
CA154 UNDER RH FRONT SEAT
FC38 UNDER CENTER OF INSTRUMENT PANEL, ON TRANSMISSION TUNNEL
