The following abbreviations are used to represent values for Control Module Pin-Out data
I Input PG Power Ground C CAN Network D Serial and Encoded Data
O Output SS Sensor / Signal Supply V S SCP Network V Voltage (DC)
B+ Battery Voltage SG Sensor / Signal Ground D2 D2B Network PWM Pulse Width Modulated
CAUTION: The information on this data page is furnished to aid the user in understanding circuit oper ation. THIS INFORMATION SHOULD BE USED FOR
REFERENCE ONLY.
NOTE: The values listed are approximately those that can be expected at the control module connector pins with all circuit connections made and all components
connected and fitted. Refer to the front of this book for detailed information and illustrations regarding the location and identification of harnesses, relays, fuses, grounds, control
modules and control module pins.
DATE OF ISSUE: June 2002
Fig. 01.6
COMPONENTS
Component Connector(s) Connector Description Location
GENERAL ELECTRONIC CONTROL MODULE FH9 22-WAY / BLACK LH ‘A’ POST
CA24 26-WAY / NATURAL
CA31 20-WAY / BLACK
FH59 12-WAY / BLACK
FH60 17-WAY / BLACK
PRIMARY JUNCTION FUSE BOX CA2 26-WAY / BLACK RH ‘A’ POST
CA56 8-WAY / BLACK
FC37 26-WAY / BLACK
FH7 6-WAY / BLACK
FH53 10-WAY / BLACK
REAR ELECTRONIC CONTROL MODULE CA63 17-WAY / BLACK LUGGAGE COMPARTMENT, RH REAR
CA100 12-WAY / BLACK
CA101 20-WAY / BLACK
CA102 22-WAY / BLACK
CA103 26-WAY / NATURAL
REAR POWER DISTRIBUTION FUSE BOX — — LUGGAGE COMPARTMENT
SWITCHED SYSTEM POWER RELAY 1 — — REAR POWER DISTRIBUTION FUSE BOX – R2
SWITCHED SYSTEM POWER RELAY 2 — — REAR POWER DISTRIBUTION FUSE BOX – R11
SWITCHED SYSTEM POWER RELAY 3 — — REAR POWER DISTRIBUTION FUSE BOX – R4
SWITCHED SYSTEM POWER RELAY 4 — — REAR POWER DISTRIBUTION FUSE BOX – R5
HARNESS IN-LINE CONNECTORS
Connector Connector Description / Location Location
BF1 6-WAY / GREY / FRONT HARNESS TO FRONT BUMPER HARNESS BEHIND FRONT BUMPER, LH SIDE
BR1 10-WAY / GREY / CABIN HARNESS TO REAR BUMPER HARNESS BEHIND REAR BUMPER, RH SIDE
CA3A/B 14-WAY / GREY / CABIN HARNESS BRIDGE LUGGAGE COMPARTMENT, LH REAR
FC33 16-WAY / GREEN / CABIN HARNESS TO FASCIA HARNESS BEHIND INSTRUMENT PANEL, RH SIDE
FH1 20-WAY / BLACK / CABIN HARNESS TO FRONT HARNESS RH ‘A’ POST, LOWER
FH39 12-WAY / GREY / FRONT HARNESS TO RH FRONT HEADLAMP LINK BEHIND FRONT BUMPER, RH SIDE
FH40 12-WAY / GREY / FRONT HARNESS TO LH FRONT HEADLAMP LINK BEHIND FRONT BUMPER, LH SIDE
FH6 16-WAY GREEN / CABIN HARNESS TO FRONT HARNESS LH ‘A’ POST, ADJACENT TO GECM
RF34 16-WAY / GREEN / CABIN HARNESS TO DOOR HARNESS ‘D’ POST, UNDER PARCEL SHELF
TT1 6-WAY / GREY / TRAILER TOWING IN-LINE CONNECTOR LUGGAGE COMPARTMENT, ADJACENT TO RH TAIL LAMP
GROUNDS
Ground Location
CA156 LUGGAGE COMPARTMENT, RH SIDE
FH77 LH LOWER ‘A’ POST, ADJACENT TO THE GENERAL ELECTRONIC CONTROL MODULE (FORWARD OF CA30)
FOR CONTROL MODULE PIN-OUT INFORMATION, UNFOLD PAGE TO LEFT.
CONTROL MODULE PIN-OUT INFORMATION
General Electronic Control Module
Pin Description and Characteristic
O FH9-21 SWITCHED SYSTEM POWER RELAYS ACTIVATE: TO ACTIVATE, GECM SWITCHES CIRCUIT TO GROUND
S FH59-1 SCP -
B+ FH59-6 BATTERY POWER SUPPLY (LOGIC): B+
S FH59-7 SCP +
PG FH60-11 POWER GROUND: GROUND
Rear Electronic Control Module
Pin Description and Characteristic
B+ CA101-3 BATTERY POWER SUPPLY: B+
O CA101-4 SWITCHED SYSTEM POWER RELAYS ACTIVATE: TO ACTIVATE, RECM SWITCHES CIRCUIT TO GROUND
S CA102-1 SCP +
S CA102-2 SCP -
PG CA102-12 POWER GROUND: GROUND
NOTE: Refer to the Appendix at the rear of this book for Network Messages.
