Jaguar S-TYPE 2004 - Manual (Page 68)

The following abbreviations are used to represent values for Control Module Pin-Out data
I Input PG Power Ground C CAN Network D Serial and Encoded Data
O Output SS Sensor / Signal Supply V S SCP Network V Voltage (DC)
B+ Battery Voltage SG Sensor / Signal Ground D2 D2B Network PWM Pulse Width Modulated
CAUTION: The information on this data page is furnished to aid the user in understanding circuit oper ation. THIS INFORMATION SHOULD BE USED FOR
REFERENCE ONLY.
NOTE: The values listed are approximately those that can be expected at the control module connector pins with all circuit connections made and all components
connected and fitted. Refer to the front of this book for detailed information and illustrations regarding the location and identification of harnesses, relays, fuses, grounds, control
modules and control module pins.
DATE OF ISSUE: June 2002
Fig. 05.3
COMPONENTS
Component Connector(s) Connector Description Location
ADAPTIVE SPEED CONTROL CHIME MODULE FC120 4-WAY / BLACK LH ‘A’ POST
ADAPTIVE SPEED CONTROL CONTROL MODULE FH107 12-WAY / BLACK BELOW LH FRONT BUMPER
DYNAMIC STABILITY CONTROL CONTROL MODULE FH103 47-WAY / BLACK ENGINE COMPARTMENT, RH FRONT
ENGINE CONTROL MODULE PI1 134-WAY / BLACK FRONT BULKHEAD, PASSENGER SIDE
FUEL / TRUNK RELEASE SWITCH PACK FC43 10-WAY / GREY INSTRUMENT PANEL
INSTRUMENT CLUSTER FC14 22-WAY / GREY INSTRUMENT PANEL
FC15 20-WAY / BLACK
FC63 22-WAY / BLACK
STEERING WHEEL — — STEERING WHEEL
TRANSMISSION CONTROL MODULE GB2 16-WAY / BLACK TRANSMISSION CONTROL VALVE ASSEMBLY
HARNESS IN-LINE CONNECTORS
Connector Connector Description / Location Location
FC4 14-WAY / GREEN / FASCIA HARNESS IN-LINE CONNECTOR BEHIND INSTRUMENT PANEL, LH SIDE
FC10 14-WAY / GREEN / FASCIA HARNESS TO FRONT HARNESS BEHIND INSTRUMENT PANEL, RH SIDE
FC117 10-WAY / BLACK / STEERING WHEEL CASSETTE STEERING COLUMN
PI41 42-WAY / BLACK / ENGINE HARNESS TO VEHICLE HARNESSES ENGINE COMPARTMENT, BULKHEAD, PASSENGER SIDE
GROUNDS
Ground Location
FC38 UNDER CENTER OF INSTRUMENT PANEL, ON TRANSMISSION TUNNEL
FH42 ENGINE COMPARTMENT, BEHIND RH HEADLAMP
FOR CONTROL MODULE PIN-OUT INFORMATION, UNFOLD PAGE TO LEFT.
CONTROL MODULE PIN-OUT INFORMATION
Adaptive Speed Control Control Module
Pin Description and Characteristic
B+ FH107-1 SWITCHED SYSTEM POWER SUPPLY: B+
PG FH107-2 POWER GROUND: GROUND
C FH107-4 CAN -
O FH107-6 CHIME MODULE DRIVE: CHIME ACTIVATE
B+ FH107-7 IGNITION SWITCHED POWER SUPPLY: B+
C FH107-10 CAN +
I/O FH107-12 FORWARD ALERT SWITCH / INDICATOR DRIVE: MONITOR FORWARD ALERT SWITCH / FORWARD ALERT INDICATOR DRIVE
Dynamic Stability Control Control Module
Pin Description and Characteristic
C FH103-11 CAN +
C FH103-12 CAN +
C FH103-14 CAN -
C FH103-15 CAN -
Engine Control Module
Pin Description and Characteristic
SS PI1-47 SPEED CONTROL SWITCH REQUEST: STEPPED RESISTANCE
I PI1-48 SPEED CONTROL SWITCHES SIGNAL GROUND: GROUND
C PI1-123 CAN -
C PI1-124 CAN +
Instrument Cluster
Pin Description and Characteristic
C FC15-8 CAN +
C FC15-9 CAN –
C FC15-18 CAN +
C FC15-19 CAN –
NOTE: Refer to the Appendix at the rear of this book for Network Messages.
