Refer to the front of this book for detailed information and illustrations regarding the location and identification of harnesses, relays, fuses, grounds, control
modules and control module pins.
DATE OF ISSUE: June 2002
Fig. 17.1
COMPONENTS
Component Connector(s) Connector Description Location
AIRBAG IGNITER – DRIVER, CURTAIN CA226 2-WAY / YELLOW HEADLINER, DRIVER SIDE
AIRBAG IGNITER – DRIVER, SIDE DB4 2-WAY / YELLOW DRIVER SEAT, SET BACK
AIRBAG IGNITER – PASSENGER, CURTAIN CA288 2-WAY / YELLOW HEADLINER, PASSENGER SIDE
AIRBAG IGNITER – PASSENGER, SIDE PB4 2-WAY / YELLOW PASSENGER SEAT, SEAT BACK
AIRBAG IGNITERS – DRIVER DUAL SW11 2-WAY / BLACK STEERING WHEEL
SW12 2-WAY / BLACK
DRIVER SEAT POSITION SWITCH DM41 2-WAY / BLACK DRIVER SEAT TRACK, LH SIDE
IMPACT SENSOR – DRIVER REAR SIDE CA230 2-WAY / BLACK LH ‘D’ POST
IMPACT SENSOR – DRIVER SIDE CA22 2-WAY / BLACK LH ‘B/C’ POST
IMPACT SENSOR – FRONT FH102 2-WAY / BLACK FRONT CROSS MEMBER, CENTER
IMPACT SENSOR – PASSENGER REAR SIDE CA246 2-WAY / BLACK RH ‘D’ POST
IMPACT SENSOR – PASSENGER SIDE CA58 2-WAY / BLACK RH ‘B/C’ POST
RESTRAINTS CONTROL MODULE CA114 24-WAY / BLACK TRANSMISSION TUNNEL, UNDER CENTER CONSOLE
CA232 40-WAY / BLACK
SEAT BELT PRETENSIONER IGNITER – CENTER REAR CA224 2-WAY / YELLOW SEAT BELT RETRACTOR
SEAT BELT PRETENSIONER IGNITER – DRIVER DM20 4-WAY / GREY SEAT BELT BUCKLE
SEAT BELT PRETENSIONER IGNITER – DRIVER SIDE REAR CA225 2-WAY / YELLOW SEAT BELT RETRACTOR
SEAT BELT PRETENSIONER IGNITER – PASSENGER PN15 4-WAY / GREY SEAT BELT BUCKLE
SEAT BELT PRETENSIONER IGNITER – PASSENGER SIDE REAR CA223 2-WAY / YELLOW SEAT BELT RETRACTOR
SEAT BELT SWITCH – DRIVER DM20 4-WAY / GREY SEAT BELT BUCKLE
SEAT BELT SWITCH – PASSENGER PN15 4-WAY / GREY SEAT BELT BUCKLE
HARNESS IN-LINE CONNECTORS
Connector Connector Description / Location Location
DM23 20-WAY / BLACK / CABIN HARNESS TO DRIVER SEAT HARNESS UNDER DRIVER SEAT
DM40 4-WAY / GREY / DRIVER SEAT ADVANCED RESTRAINT SYSTEM IN-LINE CONNECTOR UNDER DRIVER SEAT
FC42 4-WAY / GREY / CABIN HARNESS TO FASCIA HARNESS BEHIND INSTRUMENT PANEL, DRIVER SIDE
FC117 10-WAY / BLACK / STEERING WHEEL CASSETTE STEERING COLUMN
FH2 16-WAY / GREY / CABIN HARNESS TO FRONT HARNESS RH ‘A’ POST, LOWER
PN24 20-WAY / BLACK / CABIN HARNESS TO PASSENGER SEAT HARNESS UNDER PASSENGER SEAT
PN35 4-WAY / GREY / PASSENGER SEAT ADVANCED RESTRAINT SYSTEM IN-LINE CONNECTOR UNDER PASSENGER SEAT
SW9 2-WAY / YELLOW / ADVANCED RESTRAINT SYSTEM / STEERING WHEEL CASSETTE STEERING WHEEL
SW10 2-WAY / YELLOW / ADVANCED RESTRAINT SYSTEM / STEERING WHEEL CASSETTE STEERING WHEEL
GROUNDS
Ground Location
CA141 UNDER LH FRONT SEAT
CA154 UNDER RH FRONT SEAT
