The following abbreviations are used to represent values for Control Module Pin-Out data
I Input PG Power Ground C CAN Network D Serial and Encoded Data
O Output SS Sensor / Signal Supply V S SCP Network V Voltage (DC)
B+ Battery Voltage SG Sensor / Signal Ground D2 D2B Network PWM Pulse Width Modulated
CAUTION: The information on this data page is furnished to aid the user in understanding circuit oper ation. THIS INFORMATION SHOULD BE USED FOR
REFERENCE ONLY.
NOTE: The values listed are approximately those that can be expected at the control module connector pins with all circuit connections made and all components
connected and fitted. Refer to the front of this book for detailed information and illustrations regarding the location and identification of harnesses, relays, fuses, grounds, control
modules and control module pins.
DATE OF ISSUE: June 2002
Fig. 15.2
COMPONENTS
Component Connector(s) Connector Description Location
AM / FM ANTENNA AMPLIFIER CA220 NOT AVAILABLE LH C POST, ADJACENT TO REAR WINDOW
CA221 3-WAY / BLACK
AUDIO UNIT FC94 20-WAY / BLACK CENTER CONSOLE
FC96 ANTENNA CONNECTOR
FC108 FIBER OPTIC CONNECTOR
CD AUTOCHANGER CA267 3-WAY / BLACK LUGGAGE COMPARTMENT, LH REAR
RA2 FIBER OPTIC CONNECTOR
HEATED REAR WINDOW CA20 2-WAY / GREY CONNECTOR LOCATED BELOW PARCEL SHELF, LH SIDE
POWER AMPLIFIER CA263 POWER AMPLIFIER CONNECTOR LUGGAGE COMPARTMENT, LH REAR
CA264 POWER AMPLIFIER CONNECTOR
RA6 FIBER OPTIC CONNECTOR
SPEAKER – LH FRONT CA276 4-WAY / WHITE LH FRONT DOOR
SPEAKER – LH REAR CA277 4-WAY / WHITE LH REAR DOOR
SPEAKER – RH FRONT CA275 4-WAY / WHITE RH FRONT DOOR
SPEAKER – RH REAR CA278 4-WAY / WHITE RH REAR DOOR
STEERING WHEEL AUDIO SWITCHES SQ1 4-WAY / BLACK STEERING WHEEL
SUBWOOFER – LH CA6 2-WAY / WHITE PARCEL SHELF, LH SIDE
SUBWOOFER – RH CA5 2-WAY / WHITE PARCEL SHELF, RH SIDE
HARNESS IN-LINE CONNECTORS
Connector Connector Description / Location Location
FC5 2-WAY / BLACK / FASCIA HARNESS (ANTENNA) TO CABIN HARNESS (ANTENNA) BEHIND CENTER CONSOLE
FC10 14-WAY / GREEN / FASCIA HARNESS TO FRONT HARNESS BEHIND INSTRUMENT PANEL, RH SIDE
FC117 10-WAY / BLACK / STEERING WHEEL CASSETTE STEERING COLUMN
PI41 42-WAY / BLACK / ENGINE HARNESS TO VEHICLE HARNESSES ENGINE COMPARTMENT, BULKHEAD, PASSENGER SIDE
GROUNDS
Ground Location
CA157 LUGGAGE COMPARTMENT, LH SIDE AFT OF WHEEL ARCH
FC38 UNDER CENTER OF INSTRUMENT PANEL, ON TRANSMISSION TUNNEL
FOR CONTROL MODULE PIN-OUT INFORMATION, UNFOLD PAGE TO LEFT.
CONTROL MODULE PIN-OUT INFORMATION
Audio Unit – Premium
Pin Description and Characteristic
PG FC94-1 POWER GROUND: GROUND
B+ FC94-2 IGNITION SWITCHED POWER SUPPLY (I): B+
I FC94-7 TELEPHONE MUTE SIGNAL
O FC94-8 SECURITY SYSTEM GROUND SENSING: GROUND WHEN AUDIO UNIT INSTALLED
S FC94-9 SCP +
S FC94-10 SCP -
B+ FC94-11 BATTERY POWER SUPPLY: B+
I FC94-17 DIMMER CONTROLLED ILLUMINATION: PWM, 80Hz, GROUND = 0% DUTY CYCLE, B+ = 100% DUTY CYCLE
I FC94-18 STEERING WHEEL SWITCHES: STEPPED RESISTANCE
O FC94-19 D2B NETWORK WAKE-UP
D2 FC108-1 D2B NETWORK TRANSMIT
D2 FC108-2 D2B NETWORK RECEIVE
NOTE: Refer to the Appendix at the rear of this book for Network Messages.
