Fig. 06.1 – Jaguar S-TYPE 2004 User Manual
Page 72
The following abbreviations are used to represent values for Control Module Pin-Out data
I
Input
PG
Power Ground
C
CAN Network
D
Serial and Encoded Data
O
Output
SS
Sensor / Signal Supply V
S
SCP Network
V
Voltage (DC)
B+
Battery Voltage
SG
Sensor / Signal Ground
D2
D2B Network
PWM Pulse Width Modulated
CAUTION: The information on this data page is furnished to aid the user in understanding circuit oper ation. THIS INFORMATION SHOULD BE USED FOR
REFERENCE ONLY.
NOTE: The values listed are approximately those that can be expected at the control module connector pins with all circuit connections made and all components
connected and fitted.
Refer to the front of this book for detailed information and illustrations regarding the location and identification of harnesses, relays, fuses, grounds, control
modules and control module pins.
DATE OF ISSUE: June 2002
Fig. 06.1
COMPONENTS
Component
Connector(s)
Connector Description
Location
AIR CONDITIONING CONTROL MODULE – PANEL
FC27
26-WAY / GREY
CENTER CONSOLE
FC28
22-WAY / GREY
AIR CONDITIONING CONTROL MODULE – REMOTE
FC40
26-WAY / GREY
BEHIND INSTRUMENT PANEL, RH SIDE (LHD), LH SIDE (RHD)
FC41
22-WAY / GREY
AMBIENT TEMPERATURE SENSOR
FH30
2-WAY / BLACK
UNDER FRONT BUMPER, CENTER, FORWARD OF RADIATOR
AUXILIARY COOLANT PUMP
CP4
2-WAY / BLACK
ENGINE COMPARTMENT, BEHIND RADIATOR, LH SIDE
AUXILIARY COOLANT PUMP RELAY
—
—
FRONT POWER DISTRIBUTION FUSE BOX – R7
BLOWER MOTOR
AC2
6-WAY / BLACK
UNDER INSTRUMENT PANEL, RH SIDE (LHD), LH SIDE (RHD)
BLOWER MOTOR RELAY
—
—
REAR POWER DISTRIBUTION FUSE BOX – R7
COLD AIR BYPASS ACTUATOR
AC4
6-WAY / BLACK
AIR DISTRIBUTION BOX
DEFROST MODE ACTUATOR
FC29
6-WAY / BLACK
AIR DISTRIBUTION BOX
DISCHARGE TEMPERATURE SENSOR – EVAPORATOR
AC5
2-WAY / GREY
AIR DISTRIBUTION BOX
DISCHARGE TEMPERATURE SENSOR – LH
FC20
2-WAY BLACK
AIR DISTRIBUTION BOX
DISCHARGE TEMPERATURE SENSOR – RH
FC30
2-WAY BLACK
AIR DISTRIBUTION BOX
DUAL COOLANT CONTROL VALVE
CP5
3-WAY / BLACK
ENGINE COMPARTMENT, RH SIDE, REARWARD OF RADIATOR
DUAL SOLAR SENSOR
SL1
6-WAY / BLACK
INSTRUMENT PANEL GLARE SHIELD, FRONT CENTER
FLOOR MODE ACTUATOR
FC21
6-WAY / BLACK
AIR DISTRIBUTION BOX
FRESH / RECIRCULATION ACTUATOR
AC3
6-WAY / BLACK
BLOWER INTAKE
FRONT POWER DISTRIBUTION FUSE BOX
—
—
ENGINE COMPARTMENT, RH SIDE
HUMIDITY SENSOR
FC24
4-WAY / BLACK
INSTRUMENT PANEL, ADJACENT TO STEERING COLUMN
IN-CAR TEMPERATURE SENSOR
FC24
4-WAY / BLACK
INSTRUMENT PANEL, ADJACENT TO STEERING COLUMN
LH WINDSHIELD HEATER
CA122
1-WAY / BLACK
CONNECTORS LOCATED IN LH UPPER ‘A’ POST
CA279
1-WAY / BLACK
LH WINDSHIELD HEATER RELAY
—
—
FRONT POWER DISTRIBUTION FUSE BOX – R17
PANEL MODE ACTUATOR
FC22
6-WAY / BLACK
AIR DISTRIBUTION BOX
REAR POWER DISTRIBUTION FUSE BOX
—
—
LUGGAGE COMPARTMENT
WIPER PARK HEATER / RH WINDSHIELD HEATER RELAY
—
—
FRONT POWER DISTRIBUTION FUSE BOX – R21
WIPER PARK HEATER OR RH WINDSHIELD HEATER
CA65
1-WAY / BLACK
CONNECTORS LOCATED IN RH UPPER ‘A’ POST
CA71
1-WAY / BLACK
HARNESS IN-LINE CONNECTORS
Connector
Connector Description / Location
Location
AC7
2-WAY / GREY / CABIN HARNESS TO CLIMATE CONTROL HARNESS
BEHIND PASSENGER AIRBAG
CP1
10-WAY / BLACK / INTERCOOLER PUMP LINK LEAD
ENGINE COMPARTMENT, RH FRONT, ADJACENT TO RADIATOR
FC4
14-WAY / GREEN / FASCIA HARNESS IN-LINE CONNECTOR
BEHIND INSTRUMENT PANEL, LH SIDE
FC10
14-WAY / GREEN / FASCIA HARNESS TO FRONT HARNESS
BEHIND INSTRUMENT PANEL, RH SIDE
FC33
16-WAY / GREEN / CABIN HARNESS TO FASCIA HARNESS
BEHIND INSTRUMENT PANEL, RH SIDE
FC34
16-WAY / GREEN / FASCIA HARNESS IN-LINE CONNECTOR
ADJACENT TO BLOWER MOTOR
FH82
2-WAY / GREY / CABIN HARNESS TO FRONT HARNESS
RH ‘A’ POST
FH114
2-WAY / GREY / FRONT HARNESS TO CABIN HARNESS
BEHIND INSTRUMENT PANEL, LH SIDE
SL3
10-WAY / GREY / FASCIA HARNESS TO SOLAR SENSOR LINK
BEHIND INSTRUMENT PANEL, RH SIDE
GROUNDS
Ground
Location
CA30
LH LOWER ‘A’ POST, ADJACENT TO THE GENERAL ELECTRONIC CONTROL MODULE (REARWARD OF FH77)
CA50
RH LOWER ‘A’ POST, BELOW PRIMARY JUNCTION FUSE BOX
FC38
UNDER CENTER OF INSTRUMENT PANEL, ON TRANSMISSION TUNNEL
FH42
ENGINE COMPARTMENT, BEHIND RH HEADLAMP
FOR CONTROL MODULE PIN-OUT INFORMATION, UNFOLD PAGE TO LEFT.
CONTROL MODULE PIN-OUT INFORMATION
Air Conditioning Control Module – Panel
Pin
Description and Characteristic
I
FC27-1
DEFROST MODE ACTUATOR POSITION FEEDBACK: VARIABLE VOLTAGE
I
FC27-2
COLD AIR BYPASS ACTUATOR POSITION FEEDBACK: VARIABLE VOLTAGE
I
FC27-3
PANEL MODE ACTUATOR POSITION FEEDBACK: VARIABLE VOLTAGE
I
FC27-4
HUMIDITY SENSOR SIGNAL: VARIABLE VOLTAGE
O
FC27-5
DRIVER SIDE DUAL COOLANT CONTROL VALVE CONTROL DRIVE: ACTIVATE = GROUND (PWM)
O
FC27-6
PASSENGER SIDE DUAL COOLANT CONTROL VALVE CONTROL DRIVE: ACTIVATE = GROUND (PWM)
SS
FC27-7
HUMIDITY SENSOR SIGNAL SUPPLY VOLTAGE: NOMINAL 5 V
O
FC27-9
FRESH / RECIRCULATION ACTUATOR DRIVE – CLOSE: ACTIVATE = B+
O
FC27-10
FRESH / RECIRCULATION ACTUATOR DRIVE – OPEN: ACTIVATE = B+
O
FC27-11
COLD AIR BYPASS ACTUATOR DRIVE – OPEN: ACTIVATE = B+
O
FC27-12
COLD AIR BYPASS ACTUATOR DRIVE – CLOSE: ACTIVATE = B+
O
FC27-13
DEFROST MODE ACTUATOR DRIVE – OPEN: ACTIVATE = B+
SG
FC27-14
IN-CAR TEMPERATURE SENSOR SIGNAL GROUND: GROUND
I
FC27-15
FRESH / RECIRCULATION ACTUATOR POSITION FEEDBACK: VARIABLE VOLTAGE
I
FC27-16
FLOOR MODE ACTUATOR POSITION FEEDBACK: VARIABLE VOLTAGE
SG
FC27-17
ACTUATOR SIGNAL GROUND: GROUND
O
FC27-18
AUXILIARY COOLANT PUMP RELAY ACTIVATE: TO ACTIVATE, A/CCM SWITCHES CIRCUIT TO GROUND
O
FC27-19
BLOWER MOTOR RELAY ACTIVATE: TO ACTIVATE, A/CCM SWITCHES CIRCUIT TO GROUND
O
FC27-20
HEATED WIPER PARK OR HEATED WINDSHIELD RELAY(S) ACTIVATE: TO ACTIVATE, A/CCM SWITCHES CIRCUIT TO GROUND
O
FC27-21
BLOWER MOTOR CONTROL: B+ (PWM)
O
FC27-22
FLOOR MODE ACTUATOR DRIVE – OPEN: ACTIVATE = B+
O
FC27-23
FLOOR MODE ACTUATOR DRIVE – CLOSE: ACTIVATE = B+
O
FC27-24
PANEL MODE ACTUATOR DRIVE – OPEN: ACTIVATE = B+
O
FC27-25
PANEL MODE ACTUATOR DRIVE – CLOSE: ACTIVATE = B+
O
FC27-26
DEFROST MODE ACTUATOR DRIVE – CLOSE: ACTIVATE = B+
C
FC28-1
CAN -
PG
FC28-2
POWER GROUND: GROUND
B+
FC28-3
IGNITION SWITCHED POWER SUPPLY (II): B+
I
FC28-5
BLOWER MOTOR CONTROL FEEDBACK: VARIABLE FREQUENCY
I
FC28-6
PASSENGER SIDE DISCHARGE TEMPERATURE SENSOR SIGNAL: NTC SENSOR / VOLTAGE DECREASES AS TEMPERATURE INCREASES
I
FC28-7
DUAL SOLAR SENSOR SIGNAL – LH: VOLTAGE DECREASES AS LIGHT INCREASES
SG
FC28-8
AMBIENT TEMPERATURE SENSOR SIGNAL GROUND: GROUND
I
FC28-9
IN-CAR TEMPERATURE SENSOR SIGNAL: NTC SENSOR / VOLTAGE DECREASES AS TEMPERATURE INCREASES
I
FC28-10
EVAPORATOR DISCHARGE TEMPERATURE SENSOR SIGNAL: NTC SENSOR / VOLTAGE DECREASES AS TEMPERATURE INCREASES
SG
FC28-11
ACTUATORS SIGNAL GROUND: GROUND
C
FC28-12
CAN
B+
FC28-14
BATTERY POWER SUPPLY: B+
I
FC28-15
PANEL ILLUMINATION (DIMMER CONTROLLED): B+ (PWM)
SG
FC28-16
EVAPORATOR DISCHARGE TEMPERATURE SENSOR SIGNAL GROUND: GROUND
I
FC28-17
AMBIENT TEMPERATURE SENSOR SIGNAL: NTC SENSOR / VOLTAGE DECREASES AS TEMPERATURE INCREASES
I
FC28-18
DRIVER SIDE DISCHARGE TEMPERATURE SENSOR SIGNAL: NTC SENSOR / VOLTAGE DECREASES AS TEMPERATURE INCREASES
SG
FC28-19
LH / RH DISCHARGE TEMPERATURE SENSORS SIGNAL GROUND: GROUND
I
FC28-20
DUAL SOLAR SENSOR SIGNAL – RH: VOLTAGE DECREASES AS LIGHT INCREASES
SS
FC28-22
ACTUATORS SIGNAL SUPPLY VOLTAGE: NOMINAL 5 V
Air Conditioning Control Module – Remote
Pin
Description and Characteristic
I
FC40-1
DEFROST MODE ACTUATOR POSITION FEEDBACK: VARIABLE VOLTAGE
I
FC40-2
COLD AIR BYPASS ACTUATOR POSITION FEEDBACK: VARIABLE VOLTAGE
I
FC40-3
PANEL MODE ACTUATOR POSITION FEEDBACK: VARIABLE VOLTAGE
I
FC40-4
HUMIDITY SENSOR SIGNAL: VARIABLE VOLTAGE
O
FC40-5
DRIVER SIDE DUAL COOLANT CONTROL VALVE CONTROL DRIVE: ACTIVATE = GROUND (PWM)
O
FC40-6
PASSENGER SIDE DUAL COOLANT CONTROL VALVE CONTROL DRIVE: ACTIVATE = GROUND (PWM)
SS
FC40-7
HUMIDITY SENSOR SIGNAL SUPPLY VOLTAGE: NOMINAL 5 V
O
FC40-9
FRESH / RECIRCULATION ACTUATOR DRIVE – CLOSE: ACTIVATE = B+
O
FC40-10
FRESH / RECIRCULATION ACTUATOR DRIVE – OPEN: ACTIVATE = B+
O
FC40-11
COLD AIR BYPASS ACTUATOR DRIVE – OPEN: ACTIVATE = B+
O
FC40-12
COLD AIR BYPASS ACTUATOR DRIVE – CLOSE: ACTIVATE = B+
O
FC40-13
DEFROST MODE ACTUATOR DRIVE – OPEN: ACTIVATE = B+
SG
FC40-14
IN-CAR TEMPERATURE SENSOR SIGNAL GROUND: GROUND
I
FC40-15
FRESH / RECIRCULATION ACTUATOR POSITION FEEDBACK: VARIABLE VOLTAGE
I
FC40-16
FLOOR MODE ACTUATOR POSITION FEEDBACK: VARIABLE VOLTAGE
SG
FC40-17
ACTUATOR SIGNAL GROUND: GROUND
O
FC40-18
AUXILIARY COOLANT PUMP RELAY ACTIVATE: TO ACTIVATE, A/CCM SWITCHES CIRCUIT TO GROUND
O
FC40-19
BLOWER MOTOR RELAY ACTIVATE: TO ACTIVATE, A/CCM SWITCHES CIRCUIT TO GROUND
O
FC40-20
HEATED WIPER PARK OR HEATED WINDSHIELD RELAY(S) ACTIVATE: TO ACTIVATE, A/CCM SWITCHES CIRCUIT TO GROUND
O
FC40-21
BLOWER MOTOR CONTROL: B+ (PWM)
O
FC40-22
FLOOR MODE ACTUATOR DRIVE – OPEN: ACTIVATE = B+
O
FC40-23
FLOOR MODE ACTUATOR DRIVE – CLOSE: ACTIVATE = B+
O
FC40-24
PANEL MODE ACTUATOR DRIVE – OPEN: ACTIVATE = B+
O
FC40-25
PANEL MODE ACTUATOR DRIVE – CLOSE: ACTIVATE = B+
O
FC40-26
DEFROST MODE ACTUATOR DRIVE – CLOSE: ACTIVATE = B+
C
FC41-1
CAN -
PG
FC41-2
POWER GROUND: GROUND
B+
FC41-3
IGNITION SWITCHED POWER SUPPLY (II): B+
I
FC41-5
BLOWER MOTOR CONTROL FEEDBACK: VARIABLE FREQUENCY
I
FC41-6
PASSENGER SIDE DISCHARGE TEMPERATURE SENSOR SIGNAL: NTC SENSOR / VOLTAGE DECREASES AS TEMPERATURE INCREASES
I
FC41-7
DUAL SOLAR SENSOR SIGNAL – LH: VOLTAGE DECREASES AS LIGHT INCREASES
SG
FC41-8
AMBIENT TEMPERATURE SENSOR SIGNAL GROUND: GROUND
I
FC41-9
IN-CAR TEMPERATURE SENSOR SIGNAL: NTC SENSOR / VOLTAGE DECREASES AS TEMPERATURE INCREASES
I
FC41-10
EVAPORATOR DISCHARGE TEMPERATURE SENSOR SIGNAL: NTC SENSOR / VOLTAGE DECREASES AS TEMPERATURE INCREASES
SG
FC41-11
ACTUATORS SIGNAL GROUND: GROUND
C
FC41-12
CAN +
B+
FC41-14
BATTERY POWER SUPPLY: B+
SG
FC41-16
EVAPORATOR DISCHARGE TEMPERATURE SENSOR SIGNAL GROUND: GROUND
I
FC41-17
AMBIENT TEMPERATURE SENSOR SIGNAL: NTC SENSOR / VOLTAGE DECREASES AS TEMPERATURE INCREASES
I
FC41-18
DRIVER SIDE DISCHARGE TEMPERATURE SENSOR SIGNAL: NTC SENSOR / VOLTAGE DECREASES AS TEMPERATURE INCREASES
SG
FC41-19
LH / RH DISCHARGE TEMPERATURE SENSORS SIGNAL GROUND: GROUND
I
FC41-20
DUAL SOLAR SENSOR SIGNAL – RH: VOLTAGE DECREASES AS LIGHT INCREASES
SS
FC41-22
ACTUATORS SIGNAL SUPPLY VOLTAGE: NOMINAL 5 V
NOTE: Refer to the Appendix at the rear of this book for Network Messages.
