Invacare Xterra GT - Manual (Page 90)

MKIV Joystick Mounting Hardware and Joystick
Accessories
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1092604 Kit, Straight Joystick Tube with Hardware 1 1 1 A
1093069 Kit, 1/2" Offset Joystick Tube with Hardware 1 1 2 B
1027095 Plug Button, Black (7/8") 1 1 3 C
1052041 Screw, Phillips Pan Head (#4-40 x 3/8") 1 4 4
1095502 Package, Tie Wrap (11-1/2" L) 10 1 5
1093063 Spacer, Joystick Tube, Black 1 1 6
1025714 Screw, Phillips Pan Head (#10-32 x 1-1/8") 1 2 7
1093071 Clamp, Fixed Height Joystick Tube 1 1 8
1105050 Kit, Joystick Tube Mounting Hardware - Captain/
Van Seat 1 1 9 E,F
1025195 Locknut (1/4-20) 1 3 10
1101524 Spacer (1/4 x 7/16 x 5/8") 1 3 11
1105049 Clamp Assembly, Fixed Height, Captain/ Van Seat 1 1 12
1057955 Screw, Hex Head (1/4-20 x 1-1/4") 1 3 13
1055736 Kit, Toggle Switch Extension 1 1 14
1006270 Extension, Joystick, "T" Style (1560)
(4" W x 5-1/2" L) 1 1 D
1006271 Extension, Joystick, Straight Style (1561)
(1/2" W x 5" L) 1 1 D
1139422 Clamp, Height Adjustable Joystick Tube (ARM250) 1 1 15 G
A - For TCHJOY Touchpad "A" Joystick. Includes Items 3 and 4
B - For MKIV, RII, A, A+, PSF/PSR Joysticks. Captain Seats also. Includes Items 3 and 5-7
C - Touchpad "A" Joystick tube takes 2.
D - Not Shown
E - Includes items 10-13
F - Due to product improvement, the joystick mounting bracket with a separate adjustment lock were replaced with the clamp
assembly shown as of 2/20/03 and is backward compatible.
G - Can be used to replace a Fixed Height Joystick Tube Clamp in the field
