Invacare Xterra GT - Manual (Page 19)

Flip-Up Seat Plate Mounting Hardware
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1108568 Hardware, Seat Plate Mounting, Flip-Up (14 - 20" D) 1 1 1 A,B
1000208 Screw, Shoulder Hex Socket Head (5/16" x 3/8",
1/4-20) 1 1 2
1016652 Washer (5/16 x 9/16 x 1/32") 1 1 3
1108986 Washer, Flat (7/8 x 11/32 x 1/16") 1 2 4
1108981 Bracket, Prop Seat with Decals, Black 1 1 5
1070379 Washer, Spring (5/8 x 1 x 1/16") 1 2 6
1108676 Washer, Flat (7/8 x 5/8 x 1/8") 1 2 7
1108675 Bushing, Stepped (3/8" I.D.) 1 2 8
1025704 Washer, Flat (5/16 x 5/8 x 1/16") 1 6 9
1028769 Locknut (5/16-18) 1 4 10
1026158 Locknut (5/16-18) 1 2 11
1107179 Bracket, Adjustment, Black - Right (14-20" Deep) 1 1 12 B
1107180 Bracket, Adjustment, Black - Left (14-20" Deep) 1 1 12 B
1065214 Washer, Flat (3/8 x 11/16 x 1/16") 1 7 13
1069421 Screw, Shoulder Hex Socket Head (3/8 x 1",
5/16-18) 1 2 14
1064455 Screw, Shoulder Hex Socket Head (3/8 x 1-3/4",
5/16-18) 1 1 15
1106653 Decal, Notice, Lower Seat 1 1 16
1079203 Decal, Warning Pinch Point 1 1 17
1107708 Screw, Shoulder Hex Socket Head (3/8 x 3/4",
5/16-18) 1 3 18
A - Includes Items 2-18.
B - 12/4/02 all seat depths now utilize only one flip-up seat plate assembly with a material depth of 13". For 20" deep models
made before 12/4/02 and measure 14", a new flip-up seat plate must be ordered. See page titled Flip-Up Seat Plate
Assembly.
