Battery Charger and Harness
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1053161 Charger, Battery, 8 Amp, 115vac, Off Board
Dual Mode Round Plug, Lester 1 1 1
1123249 Charger, Battery, 8 Amp. 115vac (Off Board)
Single Mode Round Plug w/ AC Power Line Cord,
CTE Corp. 1 1 1 F
1123249E WARR RPLMT - Charger, Battery, 8 Amp, 115VAC
(Off Board)
Single Mode Round Plug w/ AC Power Line Cord,
CTE Corp. 1 1 1 F
1090117 Fuse - Buss Mini ATM-15 (15 AMP) 1 1 2
1108970 Package, Tie Wrap (3-7/8" L) 10 6 3
1090357 Wrap, Slit Wire Harness (1/2" O.D., 36" Long Cut To
Length) 1 1 4
1101099-NLA NLA - Fuse, Buss ATC-20 (20 AMP) 1 1 5 D
1119230 Fuse - Buss Mini ATM-20 (20 AMP) 1 1 5 E
1106158-NLA NLA - Harness, Wiring 1 1 6 A
1108985-NLA NLA - Harness, Wiring 1 1 7 B
1108695-NLA NLA - Cable, Programmer Extension (9" L) 1 1 8
1092913 Cable, Drive Lockout Sensor 1 1 9 C
1089627 Cord, AC Power, 115VAC, 2 Prong Off-Board (11'
6" L) 1 1 10
A - For MKIV Quad Pulse Controller.
B - For MKIV RII 80 AMP Controller.
C - Sensor cable is used with a full recline captain seat.
D - Before 4/1/03
E - After 3/31/03
F - CTE charger introduced and standard on-chair 4/1/04. Used on Gel Cell or AGM (Absorbed Glass Mat) batteries. Serial
number starts with 04A00000001. For wet cell batteries refer to the Lester charger.
NOTE:
