Invacare Xterra GT - Manual (Page 61)

Pivot/Slide Tube and
1650, 1450, 1350 Aluminum Footplates
NOTE: Heel loops are not included. See Footrest and Legrest Accessories.
NOTE: For complete pivot/slide tube and footplate assemblies, see Front Rigging Reference Charts.
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1027097 Plug Button, Black (3/4") 1 1 1
1048834 Pivot/Slide Tube w/ Plug Button, Black 1 1 2
1098906 Pivot/Slide Tube w/ Plug Button, Black (2" Longer) 1 1 2
1086482 Pivot/Slide Tube w/ Plug Button, Black (4" Longer) 1 1 2
1100571 Pivot/Slide Tube w/ Plug Button, Deluxe, Black 1 1 2
44200X059 Footplate, Aluminum, Small, Black (6-3/4" W x 6" L) 1 1 3
44200X027 Footplate, Aluminum, Medium, Black (7-3/4" W x 6"
L) 1 1 3
1043659 Footplate, Aluminum, Deluxe, Black - Right (8" W x
5-3/4" L) 1 1 3
1043660 Footplate, Aluminum, Deluxe, Black - Left (8" W x
5-3/4" L) 1 1 3
44200X025 Footplate, Aluminum, Extra Large, Black - Right (8"
W x 8-1/2" L) 1 1 3
44200X026 Footplate, Aluminum, Extra Large, Black - Left (8" W
x 8-1/2" L) 1 1 3
1016346 Cap, End, Tube, Black (7/8") 1 1 4
1027095 Plug Button, Black (7/8") 1 1 4
1006981 Spring, Tension 1 2 5
1036120 Spring 1 2 5
1036123 Spring, Leaf 1 1 5
7930354 Package, Phillips Head Screw (#8-32 x 3/8") 25 2 6 A
1070168 Plug, Push, Footplate 1 1 7
A - Deluxe takes quantity (1). NOTE:
60
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-058
