Footrest and Legrest Accessories
AT5543 Adjustable Angle Heel Loops and Hardware
Part Number Description Consist of:
(2) Heel Loops
(4) Screw, Phillips Pan Head
(1/4-20 x 2-1/4")
(4) Spacer
(4) Locknut (1/4-20)
Kit, Heel Loop w/ Hardware,
Adjustable Angle Footplate (Pair)
1160723
(2) Heel Loops w/ Ankle Strap
(4) Screw, Phillips Pan Head
(1/4-20 x 2-1/4")
(4) Spacer
(4) Locknut (1/4-20)
Kit, Heel Loop w/ Ankle Strap and
Hardware, Adjustable Angle
Footplate (Pair)
1160724
(2) Screw, Phillips, Pan Head
(1/4-20 x 2-1/4")
(2) Spacer
(1/4 x 11/32 x 1-3/4")
(2) Hex Nut w/ Nylon Cap (1/4-20)
(2) Flat Washer
(1/4 x 5/8 x 1/16")
1035931
Kit, Heel Loop Attaching Hardware
Attaching Hardware Only
Toe Loops 1345
Part Number Description
Toe Loop (Single) 04572X025
Toe Loops without Hardware (Pair) 1037087
Attaching Hardware - AT5543 Footplates w/ Toe Loops
Part Number Description Consist of:
(4) Screw, Phillips Pan Head (#10-32
x 1/2")
(4) Locknut (#10-32)
Hardware, Toe Loops and Footplate
(Pair)
1104749
Attaching Hardware - 1651, 1650, 1450 and 1350 Footplates w/ Toe Loops
Part Number Description Consist of:
