Footrest and Legrest Accessories
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1032243 Strap, Calf w/ Hook and Loop (36" L) 1 1
1032214 H-Strap (24" L) -- -- D
1032215 H-Strap (26" L) 1 1 E
1032216 H-Strap (31" L) 1 1 F
1026987 Guard, Impact (8" L) 1 2 A
1026846 Guard, Impact (12" L) 1 2 B
See Chart Footrest and Legrest Accessories (Not Including
AT5543) 1 1 C
See Chart Heel Loop Attaching Hardware (Not Including
AT5543) 1 1 C
See Chart AT5543 Adjustable Angle Heel Loops and Hardware 1 1 C
See Chart Attaching Hardware - AT5543 Footplates w/ Toe
Loops 1 1 C
See Chart Toe Loops 1345 1 1 C
See Chart Attaching Hardware - 1651, 1650, 1450 and 1350
Footplates w/ Toe Loops 1 1 C
A - For 70 deg. Tapered Footrest
B - For Cage Style Footrest
C - Not Shown
D - 14" wide seats
E - 15-16" wide seats
F - 17" and wider seats NOTE:
Footrest and Legrest Accessories (Not Including AT5543)
Footplate Type
Attaching
Hardware
Pair #
Heel Loop
Single #
Heel Loop
Pair #
Heel Loop
with Ankle
Strap
Single #
Right
Heel Loop
with Ankle
Strap
Single #
Left
Heel Loop
with Ankle
Strap
Pair #
1035931 1035906 1035909 1035908 1035912 1028412
Composite
(1651)
Small 14" Wide
or
15-17" Wide
Tapered
1035931 1035918 1035920 1035919 1035917 1017621
Composite
(1651)
Medium 15-16"
Wide or
18-19" Wide
Tapered
1035931 1035930 1035933-NLA 1035932-NLA 1035917 1017621
Composite
(1651)
Large 17-20"
Wide or
20" Wide
Tapered
63
