4-Pole Motor and Gearbox Assembly
Item
Number
Description Right Left
1108447-NLA 1108447-NLA Screw, Phillips Pan Head
(M4 x .7 x 8 mm)
12.
See Note(s) H See Note(s) H
1105835 1105834 Motor Mount 13.
1071505
1071505
Screw, Socket w/ Patch
(M6 x 20)
14.
See Note(s) E
1071504 1071504
Screw, Socket w/ Patch
(M6 x 35)
15.
1108562 1108562 Kit, Motor Mounting
Hardware
16.
See Note(s) C See Note(s) C
A - Includes items 2-12.
B - Includes items 7-12.
C - Includes items 14 and 15.
D - When a new gearbox or mounting screws are ordered, (2 ea.) metric and (2 ea.) non-metric screws (item 9) must be ordered.
Invacare Corp. utilizes alternate suppliers for this part number.
E - The Kit comes with a quantity of 3 Screws, the drawing only shows a quantity of 2.
F - Kit includes (4) Brushes, (4) Brush Caps and Instruction Sheet.
G - Use existing screws when installing the Brake Repair Kit. The Motor Brake Mounting Screws are not saleable.
H - No longer available, use 1108452 as the replacement part. NOTE:
73
