Invacare Xterra GT - Manual (Page 88)

MKIV Joysticks
PSF and PSR
NOTE: PSR STANDARD joystick configuration below show the on/off switch on the left side for part #
1075196. When the on/off switch is required on the right side, refer to part number 8881075196 and order
as a configurated part.
Item Number Description PSF PSR
1075196 N/A
Joystick
Assembly
See Pictorial
8881075196 1075195-NLA
Joystick
Assembly
See Pictorial
1070542-NLA N/A
Joystick
Assembly
See Pictorial
1070543 N/A
Joystick
Assembly
See Pictorial
1070544-NLA N/A
Joystick
Assembly
See Pictorial
1040217 1040217 Knob, Joystick 1
1040218 1040218 Skirt, Joystick 2
1036764-NLA 1036764-NLA Inductive, Joystick 3
50000X364 50000X364 Boot, Joystick 4
1079925-NLA 1075034-NLA Overlay, Joystick Decal 5
1036750 1036750 Cable Assembly 6
1040225 1040225 Potentiometer, Speed 7
1025516 1025516 Knob, Potentiometer 8
1040185 1040185 Switch, On/Off Momentary 9
1010047 1010047
Switch, Push Button SPST
Momentary
10
1010048-NLA N/A Switch, Push Button SPST 11
1010049-NLA 1010049-NLA Boot, Switch 12
1058464 1058464 Boot, Switch 13
87
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-058
