Invacare Xterra GT - Manual (Page 45)

Front Riggings Reference Chart
AT5544, 60HD, 70NHD, and PW93
NOTE: Calf pads with attaching hardware not included on legrest.
NOTE: Pivot/Slide tube ataching hardware not included.
NOTE: Pivot/Slide tube and footplates do not include heel loops. See footrest and legrest accessories.
Pivot/Slide Tubes
Model Number Description
Composite footplate with
9-7/8" curved pivot/slide tube.
1651
Adjustable angle footplate wtih
9-7/8" straight pivot/slide tube.
AT5543
Deluxe aluminum footplate with
"L" style pivot/slide tube.
1450
Extra large footplate with
"L" style pivot/slide tube.
1350
Upper Support Assemblies
NOTE: Pivot/Slide tube and footplate are interchangeable with the support assemblies listed here.
Side AT5544 60HD 70NHD PW93
8881070776 8881053149 8881053158 8881045291
Right
See Note(s) A See Note(s) A See Note(s) A See Note(s) A
8881070777 8881053148 8881053157 8881045292
Left
See Note(s) A See Note(s) A See Note(s) A See Note(s) A
A - Specify frame color when ordering, see page titled "Frame Finishes and Touchup Paints". NOTE:
Pivot/Slide Tube and Footplates
AT5543
16-20" Wide
1651
14" Wide
1651
15-16" Wide
1651
17-20" Wide
1350
17-20" Wide
AT5543
14-15" Wide
1062756 1060444 1026395 1057879 1057869 1057859 Right
1062757 1060445 1026396 1057880 1057870 1057860 Left
