MKIV Joystick Options
A - Includes the joystick tube and items 10 and 11
B - Includes items 13-17
C - For On-Chair model numbers 1678 and 1679. Includes the joystick tube and item 19
D - Includes items 22-26
E - Includes items 28-30
F - Includes the joystick tube, items 33 and 34
G - Individual components are non-saleable.
H - Before 5/24/04
I - After 5/23/04. The Egg Reset Switch replaced the Red Flex Ribbon (Tape) Reset Switch
J - Not Shown and used with the Heavy Duty and Touch Pad Joystick
K - Not Shown and used with the Remote Joystick
L - Can be used to replace a Fixed Height Joystick Tube Clamp in the field
M - No longer available as a service part in the field.
N - Part #1017612 is no longer available as a service part individually. Order item #27 as a replacement. NOTE:
111
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-058
