Base Frame, Suspension Arms, and Torsion Bar
Item
Number Part Number Description Note
Quantity Per
Package Assembly
40117X006 Bearing (5/8") 1 4 1
1082708 Bearing (3/8") 1 4 2
1108559 Pin, Shoulder (3/8 x 1-3/8") 1 2 3
1028769 Locknut (5/16-18) 1 2 4
1105770 Plug Button, Frame, Black 1 2 5
1095489 Decal, Invacare 3-D Logo (2-1/2" L) 1 1 6
1119281 Plate, Name, Patent Numbers 1 1 7
8881106098 Frame Assembly with Insert, Color 1 1 8 A,D
1105787 Bearing, Flange (3/4") 1 2 9
1108437 Bumper, Rubber (1" Diameter x 5/8") 1 2 10
40117X006 Bearing (5/8") 1 2 11
1108980-NLA NLA - Decal, Xterra GT 1 1 12
8881107169-NL
A
NLA - Arm Suspension - Right 1 1 13 B,D
8881107170-NL
A
NLA - Arm Suspension - Left 1 1 13 B,D
1025704 Washer, Flat (5/16 x 5/8 x 1/16") 1 2 14
1093978 Flange (5/16" I.D.) 1 4 15
1107167 Bar, Torsion, Black 1 1 16
1108984 Clip, Pin Hitch (3/32 x 1-5/8") 1 2 17
1106159 Torsion Bar Assembly, Black 1 1 18 C
1110717 Ring, Tolerance 1 2 19
A - Includes Base Frame and Items 1-7 and 19.
B - Includes Items 9-12 and 19.
C - Includes Items 14-17.
D - Specify frame color when ordering. NOTE:
69
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-058
