Fenders and Shrouds
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1028484 Screw, Phillips Pan Head Tap (#10-32 x 1/2") 1 2 1
1107712 Plate, Fender 1 1 2
1106156-NLA NLA - Fender - Right 1 1 3
1106157-NLA NLA - Fender - Left 1 1 3
1108563 Fender Assembly 2 1 4 A
1028484 Screw, Phillips Pan Head Tap (#10-32 x 1/2") 1 2 5
1070587 Washer, Flat (3/16 x 5/8 x 1/16") 1 2 6
1108694 Hardware, Shroud Mounting 1 1 7 B
1090147 Decal, Invacare Medallion - Large 1 1 8
1106125-NLA NLA - Shroud, Rear 1 1 9
1108454-NLA NLA - Shroud with Decal, Front with Charger Port
Plugs 1 1 10 C
1106144-NLA NLA - Shroud with Decal
Front without Charger Port Plugs 1 1 10 D
1104803 Plug Button, Black (1") 1 2 11
A - Includes Items 1-3.
B - Includes Items 5 and 6.
C - MKIV RII Controller
D - MKIV Quad Pulse Controller NOTE:
79
