Battery Top Cover and Tray Assembly
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1079635 Bushing, Flange 1 2 1
1044939 Screw, Hex Head (5/16-18 x 1-3/4") 1 2 2
1074133 Washer, Steel (5/16 x 3/4 x 1/16") 1 2 3
1026906 Locknut (5/16-24) 1 1 4
1025704 Washer, Flat (5/16 x 5/8 x 1/16") 1 2 5
1106121 Screw, Hex Head (5/16-24 x 8-1/2") 1 1 6
1028769 Locknut (5/16-18) 1 2 7
1108693 Hardware, Battery Tray Mounting 1 1 8 A
1106143-NLA NLA - Strap and Buckle Assembly, Battery Tray 1 1 9
1106130-NLA NLA - Grommet, Rubber 1 1 10
1106142 Bracket, Port, Black 1 1 11 B
1028769 Locknut (5/16-18) 1 2 12
1106097-NLA NLA - Rod, Spade 1 1 13
1106148-NLA NLA - Lug, Hex - Front 1 2 14
1040226 Rivet, Nylon 1 1 15
1037373 Cover, Splash 1 1 16
1108695-NLA NLA - Cable, Programmer Extension (9" L) 1 1 17
1134086 Screw, Socket Button Head w/ Patch (#10-32 x
1/2") 1 2 18
1106139-NLA NLA - Battery Tray Assembly 1 1 19 B,C
1108566-NLA NLA - Battery Tray Assembly 1 1 19 D,F
1106129-NLA NLA - Top Cover Assembly, Battery 1 1 20
1106146-NLA NLA - Strap with Clip Assembly, Battery Top Cover 1 1 21
1114843-NLA NLA - Decal, Warning 1 1 22
1089385 Fuse, MIDI (Non-G/B & G/B) (80 AMP) 1 1 E
1108974 Hardware, Terminal, 22NF Batteries
Hardware includes:
battery clamps,
battery clamp caps (red and black),
small terminal covers (red and black),
1/4-20 x 7/8" hex flange screws,
1/4-20 hex flange locknuts,
cable ties,
and instruction sheet for two batteries. 1 1 E
A - Includes Items 1-7.
B - For MKIV Quad Pulse Controllers Only.
C - Includes Items 9-18.
D - Includes Items 9, 10, 12-14, and 18.
E - Not Shown
F - For MKIV RII Controllers Only. NOTE:
83
