ASBA Seat Frame and Hardware
16-20" Wide
NOTE: 14" and 15" seat depths are achieved by using CJ back mounting hardware.
Item
Number Part Number Description Note
Quantity Per
Package Assembly
See Chart # 1 ASBA Seat Frame and Hardware 1 1 1 A
1029501 Plug Button, Black (1") 1 2 2
1090768 Kit, Lock Handle w/Rivets (Pair) 2 1 3
47471X074 Spring, Arm Lock 1 2 4
1028594 Pin, Arm Lock, Black 1 2 5
A - Includes seat frame and items 2-5 NOTE:
# 1 - Seat Frame with Hardware
Seat Width 14-17" Deep 18-19" Deep 20" Deep
1108960 1108954 1108948 16" Wide
1108961 1108955 1108949 17" Wide
1108962 1108956 1108950 18" Wide
1108963 1108957 1108951 19" Wide
1108964 1108958 1108952 20" Wide
12
