Seat Pan and Mounting Hardware
NOTE: 14-15" Wide seat depths are achieved by using CJ back cane mounting hardware.
Item
Number Part Number Description Note
Quantity Per
Package Assembly
See Chart #1 Seat Pan 1 1 1
1070459 Kit, Seat Pan Mounting Hardware 1 1 6 A
Screw, Hex Head (1/4-20 x 1-5/8") 1 2 2
Screw, Hex Head (1/4-20 x 1-1/2") 1 4 3
Spacer (1/4 x 3/8 x 3/16") 1 4 4
Locknut (1/4-20) 1 6 5
A - Includes Items 2-5. NOTE:
#1 - Seat Pan
Seat Width 20" Deep 14-15" Deep 16" Deep 17" Deep 18" Deep 19" Deep
1066055 1066044 1066033 1066022 1066011 1066022 14" Wide
1066056 1066045 1066034 1066023 1066012 1066023 15" Wide
1066057 1066046 1066035 1066024 1066013 N/A 16" Wide
1066058 1066047 1066036 1066025 1066014 N/A 17" Wide
1066059 1066048 1066037 1066026 1066015 N/A 18" Wide
1066060 1066049 1066038 1066027 1066016 N/A 19" Wide
1066061 1066050 1066039 1066028 1066017 N/A 20" Wide
20
