80C186EA 80C188EA 80L186EA 80L188EA
DC SPECIFICATIONS (80C186EA 80C188EA)
Symbol Parameter Min Max Units Conditions
V
CC
Supply Voltage 4 5 5 5 V
V
IL
Input Low Voltage for All Pins b 0 5 0 3 V
CC
V
V
IH
Input High Voltage for All Pins 0 7 V
CC
V
CC a 0 5 V
V
OL
Output Low Voltage 0 45 V I
OL e 3 mA (min)
V
OH
Output High Voltage V
CC b 0 5 V I
OH e b 2 mA (min)
V
HYR
Input Hysterisis on RESIN 0 30 V
I
IL1
Input Leakage Current (except g 10 m A 0V s V
IN s V
CC
RD QSMD UCS LCS MCS0 PEREQ
MCS1 ERROR LOCK and TEST BUSY)
I
IL2
Input Leakage Current b 275 m A V
IN e 0 7 V
CC
(RD QSMD UCS LCS MCS0 PEREQ (Note 1)
MCS1 ERROR LOCK and TEST BUSY
I
OL
Output Leakage Current
g 10 m A
0 45 s V
OUT s V
CC
(Note 2)
I
CC
Supply Current Cold (RESET)
80C186EA25 80C188EA25 105 mA (Notes 3 5)
80C186EA20 80C188EA20 90 mA
80C186EA13 80C188EA13 65 mA
I
ID
Supply Current In Idle Mode
80C186EA25 80C188EA25 90 mA (Note 5)
80C186EA20 80C188EA20 70 mA
80C186EA13 80C188EA13 46 mA
I
PD
Supply Current In Powerdown Mode
80C186EA25 80C188EA25 100 m A (Note 5)
80C186EA20 80C188EA20 100 m A
80C186EA13 80C188EA13 100 m A
C
OUT
Output Pin Capacitance 0 15 pF T
F e 1 MHz (Note 4)
C
IN
Input Pin Capacitance 0 15 pF T
F e 1 MHz
NOTES
1 RD QSMD UCS LCS MCS0 PEREQ MCS1 ERROR LOCK and TEST BUSY have internal pullups that are only acti-
vated during RESET Loading these pins above I
OL e b 275 mA will cause the processor to enter alternate modes of
operation
2 Output pins are floated using HOLD or ONCE Mode
3 Measured at worst case temperature and V
CC
with all outputs loaded as specified in the AC Test Conditions and with the
device in RESET (RESIN held low) RESET is worst case for I CC
4 Output capacitance is the capacitive load of a floating output pin
5 Operating conditions for 25 MHz are 0 C to a70 C V
CC e 5 0V g 10%
