Page 61
SECTION 6—SEAT
61
Everyday and Sport Series Wheelchairs
FIGURE 6.3 Adjusting Transformer Seat Height
DETAIL “A” -
FRONT VIEW
Wheelchair Frame
Footrest
Tubing
Coved
Washer
Mounted Screw/
Threaded Sleeve
Adjustment Holes
Half Clamp
Mounting Screw
Coved Washer
Half Clamp
DETAIL “B”
Adjustment
Screw
