Figure 5.6 – Invacare Top End X-Terminator QR User Manual
Page 40
SECTION 5—WHEELS
Everyday and Sport Series Wheelchairs
40
FIGURE 5.6 Opening/Closing Camber Clamps
Side View of Quick Release Lever
Camber Clamp
Closed Position
Open Position
Quick
Release
Lever
Side View of Standard Camber Clamp
Camber Clamp
Socket Screw
Rear View of Suspension Camber Clamp
Camber Clamp
Hex Screw
Camber Insert
Axle Tube
