4 LIVE DISPLAY MODE Click these icons to select display mode.
5 PAUSE Click this icon to pause the display screen.
6 CAPTURE Click this icon to capture the image from live display.
7 SETUP Click this icon to control remotely the setting of DVR.
8 PAN/TILT Use these buttons to control the PAN/TILT features on the remote
camera.
9 ZOOM/FOCUS Use these buttons to control the ZOOM/ FOCUS features on the
remote camera.
10 AUDIO The audio can be turned on or off by clicking the audio icon.
11 CONNECTION STATUS Shows the client connection information.
8-2-2. Search and Playback
Figure 8.2.2. Main user interface – Search & Playback
Table 8.2.2. Main controls – Search & Playback
No Name Description
1 DATE & TIME Displays the current date and time.
2 Connect/Disconnect Click this icon to connect to the DVR
69
