Switch view between quad and full screen mode displaying highlighted channel.
BACKUP Press the BACKUP button to archive the still image or video clip into USB stick or CD
media.
5. Archiving Video
You can archive a still image or video clip to a USB stick or CD media and hard drive.
5-1. Capturing and transferring still images or video onto USB or CD media.
STILL IMAGE ARCHIVE
Still images can be captured and archived onto the USB stick, CD media or hard drive in live mode or while
playing back recorded video. In LIVE mode, press the BACKUP button to launch the archive function.
When you press BACKUP button, the archiving screen will display as Figure 5.1.1. And the DVR will ask
which media you will take for archiving as Figure. 5.1.2.
Once you select the media, the system will start to archive the data to the selected media.
Figure 5.1.1. STILL IMAGE Archiving Screen
51
