Maxtor SSA-0412 - Manual (Page 24)

MOTION-
SENSITIVITY
Set the motion sensitivity for the specified channel.
Control the motion sensitivity from 1 to 9.
SENSOR TYPE Set the type of sensor for the specified channel from none,
N/O (normal open), and N/C (normal closed).
PRE RECORD Enable/disable pre-event recording. Pre-event recording time is 5 seconds
and only intra-frames are recorded for pre-event recording.
POST-EVENT
RECORD
Set post event recording time duration for the specified channel (1~30
seconds)
ALARM Enable/disable alarm generation for the specified channel.
ALARM DURATION Set alarm time duration for the specified channel. (1~60 seconds)
AUDIO Enable/disable audio for the specified channel
SCHEDULE Set recording schedule. If this menu item is selected, screen will change as
shown in figure 3.3.3.
3-3-1. Quick record setting
Figure 3.3.2 Quick RECORD setting screen
24
