Indicates that alarm output is activated.
Indicates that lock function for a remote control is set.
Alarm indicator. When there is an alarm (sensor or motion alarm) in the video
channel, this icon will be highlighted bright red.
Indicates that a network client is connected to the DVR.
Indicates that sequencing mode is enabled.
Table 4.1.2. Button functions in LIVE screen
BUTTON DESCRIPTION
Select channel to be displayed in full screen mode.
Switch between full screen and quad display mode.
SEQ Press to start auto sequencing of the screen in full screen mode. (Toggle)
RECORD Press to start and stop manual recording.
SEARCH
Press to go to the search menu.
Event search /Time line search /Log /Archive search
BACKUP
Press to capture a still image. The still image will be stored into hard drive. It can be
transferred to the USB device or CD title.
PTZ Press to control PTZ operation
SETUP Press to launch SETUP menu.
ESC
Press for temporal storage of the changed value or to return to the previous menu
screen.
4-2. SEARCH screen
Press the SEARCH button in live mode to enter SEARCH screen.
The password screen will appear as in figure 4.2.1. And then, SEARCH screen(figure 4.2.2) will be
appeared after input the right password.
