Figure 4.4.1. PLAYBACK mode screen

Table 4.4.1. Button functions in PLAYBACK mode

BUTTON

DESCRIPTION

ESC

Return to the previous menu screen, search list, or exit menu

Press to rewind the footage at 1x, 2x, 4x and 8x speeds. Reverse playback speed is

shown as -1x (normal), -2x (2 times normal), -4x (4 times normal) and -8x (8 times

normal) at the bottom right of the screen.

Jump/Step backward. – The playback position moves 60 seconds backward.

PLAY/PAUSE Press to play or pause recorded video.

Jump/Step forward –Playback position moves 60 seconds forward.

Press to fast forward the footage at 1x, 2x, 4x and 8x speeds. Playback speed is

indicated as +1X, +2X, +4X and +8X for normal, twice, 4 times and 8 times of the regular

speed at the bottom right of the screen.

Select channel 1 to be highlighted.

Select channel 2 to be highlighted.

Select channel 3 to be highlighted.

Select channel 4 to be highlighted.
