OM-196 188 Page 87
Ref. 154 109
Use mode select button to select
mode to be changed (see 8-19).
Use pulse panel parameter select
button to select parameter to be
changed (see 8-20).
1 Increase Button
Press button to increase value that
is underlined by the moving line.
2 Decrease Button
Press button to decrease value that
is underlined by the moving line.
1
2
> Prg 1
Pulse
035” Steel
Argon – Oxy
> Prg 2
Pulse
045” Steel
Argon – Oxy
> Prg 3
Pulse
052” Steel
Argon – Oxy
> Prg 2
Pulse
045” Steel
Argon – Oxy
8-21. Setup Pendant Parameter Increase And Decrease Buttons
Increase
Decrease
Increase
