6. weld interface board pc12 diagnostic led’s – Miller Electric Welder User Manual
Page 35
OM-196 188 Page 29
1
Weld Interface Board PC12
Diagnostic LED’s are visible inside
unit, located on PC12 (see illustration
for board location).
Refer to Section 5-7 for information
on diagnostic LED’s.
Reinstall cover and left side panel
after checking diagnostic LED’s.
191 842
1
5-6.
Weld Interface Board PC12 Diagnostic LED’s
LED12
LED11
LED10
LED9
LED6
LED5
LED8
LED7
LED4
LED3
LED2
LED1
LED13
Top View
