OM-196 188 Page 79
8-7. Program 5 – 1.0 mm 316 (.040”), 98-2 Argon-CO
2
Wire Size/Type: 1.0 mm (.040”) 316 Gas: Ar - CO
2
/ 19 L/min (40 CFH)
MPM / IPM Apk Abk PPS PWms Vpk COMMENTS
19.1 / 750 443 144 183 2.6 34.0
17.8 / 700 425 130 175 2.5 33.8
16.5 / 650 407 116 167 2.4 33.6
15.2 / 600 390 103 160 2.3 33.4
14.0 / 550 372 89 152 2.2 33.1
12.7 / 500 355 75 145 2.1 32.9
11.4 / 450 351 71 136 2.0 32.7
10.2 / 400 348 68 128 2.0 32.5
8.9 / 350 344 64 119 1.9 32.3
7.6 / 300 340 60 110 1.9 32.1
6.7 / 265 330 54 99 1.8 31.1
5.7 / 225 320 48 89 1.8 30.1
4.7 / 185 310 41 78 1.7 29.0
3.8 / 150 300 35 67 1.7 28.0
2.8 / 110 290 29 56 1.6 27.0
8-8. Program 6 – 1.2 mm 316 (.045”), 98-2 Argon-CO
2
Wire Size/Type: 1.2 mm (.045”) 316 Gas: Ar - CO
2
/ 19 L/min (40 CFH)
MPM / IPM Apk Abk PPS PWms Vpk COMMENTS
18.6 / 735 491 180 215 3.3 35.2
17.1 / 675 480 175 205 3.2 34.4
15.7 / 620 469 164 195 3.1 33.6
14.3 / 565 458 153 185 3.1 32.8
12.9 / 510 446 141 175 3.0 32.0
11.4 / 450 435 130 165 2.9 31.2
10.0 / 395 421 117 151 2.7 30.7
8.6 / 340 408 105 138 2.6 30.3
7.1 / 285 394 92 124 2.4 29.8
5.7 / 225 380 80 110 2.3 29.3
5.1 / 200 375 75 100 2.2 29.1
4.4 / 175 370 70 90 2.1 28.9
3.8 / 150 365 65 80 1.9 28.6
3.2 / 125 360 60 70 1.8 28.4
2.5 / 100 355 55 60 1.7 28.2
