Miller Electric Welder User Manual
Page 84
OM-196 188 Page 78
8-5.
Program 3 – 1.2 mm Steel (.045”), 80-20 Argon-CO
2
Wire Size/Type: 1.2 mm (.045”) Steel
Gas: Ar - CO
2
/ 19 L/min (40 CFH)
MPM / IPM
Apk
Abk
PPS
PWms
Vpk
COMMENTS
19.1 / 750
570
134
246
2.9
41.2
17.8 / 700
560
130
235
2.9
40.6
16.5 / 650
550
126
224
2.9
40.0
15.2 / 600
540
123
213
2.9
39.5
14.0 / 550
530
119
201
2.8
38.9
12.7 / 500
520
115
190
2.8
38.3
11.4 / 450
502
107
177
2.7
37.4
10.2 / 400
485
100
165
2.7
36.6
8.9 / 350
467
92
152
2.6
35.7
7.6 / 300
450
85
140
2.6
34.9
6.4 / 250
435
74
120
2.4
34.1
5.1 / 200
420
64
100
2.3
33.4
3.8 / 150
405
53
80
2.1
32.6
2.5 / 100
390
43
60
1.9
31.8
1.3 / 50
375
32
40
1.7
31.0
8-6.
Program 4 – .8 mm 316 (.030”), 98-2 Argon-CO
2
Wire Size/Type: .8 mm (.030”) 316
Gas: Ar - CO
2
/ 19 L/min (40 CFH)
MPM / IPM
Apk
Abk
PPS
PWms
Vpk
COMMENTS
15.6 / 615
301
66
117
2.0
33.1
15.2 / 600
300
65
115
2.0
33.1
14.0 / 550
295
61
109
1.9
33.0
12.7 / 500
290
58
103
1.9
33.0
11.4 / 450
285
54
96
1.8
32.9
10.2 / 400
280
50
90
1.8
32.9
9.2 / 360
271
47
84
1.8
32.1
8.3 / 325
263
45
78
1.8
31.3
7.3 / 290
254
42
71
1.7
30.5
6.4 / 250
245
40
65
1.7
29.7
5.6 / 220
246
38
56
1.6
29.7
4.8 / 190
248
37
47
1.6
29.8
4.0 / 160
249
35
37
1.5
29.8
3.2 / 125
250
34
28
1.4
29.9
3.0 / 120
250
34
26
1.4
29.9
