OM-196 188 Page 84
8-17. Program 7 – .8 mm Steel (.030”), 98-2 Argon-Oxy
Wire Size/Type: .8 mm (.30”) Steel Gas: Ar - Oxy / 19 L/min (40 CFH)
MPM / IPM Apk Abk PPS PWms Vpk COMMENTS
19.7 / 775 384 121 143 2.0 33.9
17.8 / 700 375 110 135 1.9 33.6
15.9 / 625 366 99 127 1.8 33.3
14.0 / 550 358 88 120 1.7 33.0
12.1 / 475 349 76 112 1.6 32.6
10.2 / 400 340 65 104 1.5 32.3
8.9 / 350 334 56 94 1.5 31.8
7.6 / 300 328 48 85 1.5 31.3
6.4 / 250 321 39 75 1.4 30.7
5.1 / 200 315 30 65 1.4 30.2
4.4 / 170 306 29 58 1.3 29.5
3.8 / 150 298 28 51 1.3 28.9
3.2 / 125 289 26 44 1.2 28.2
2.5 / 100 280 25 37 1.1 27.6
1.9 / 75 271 24 30 1.0 26.9
8-18. Program 8 – 1.0 mm Steel (.040”), 98-2 Argon-Oxy
Wire Size/Type: 1.0 mm (.040”) Steel Gas: Ar - Oxy/ 19 L/min (40 CFH)
MPM / IPM Apk Abk PPS PWms Vpk COMMENTS
17.9 / 705 451 90 201 2.4 33.7
17.8 / 700 450 90 200 2.4 33.6
16.5 / 650 440 90 192 2.4 32.8
15.2 / 600 430 90 185 2.4 32.0
14.0 / 550 420 90 177 2.3 31.1
12.7 / 500 410 90 170 2.3 30.3
11.4 / 450 392 82 162 2.3 29.4
10.2 / 400 375 75 155 2.3 28.5
8.9 / 350 357 67 147 2.2 27.5
7.6 / 300 340 60 140 2.2 26.6
6.4 / 250 320 55 120 2.1 26.9
5.1 / 200 300 50 100 2.0 27.3
3.8 / 150 280 45 80 1.9 27.6
2.5 / 100 260 40 60 1.8 27.9
2.4 / 95 257 39 57 1.8 27.9
