OM-196 188 Page 80
8-9. Program 7 – 1.0 mm 308L (.040”), 98-2 Argon-CO
2
Wire Size/Type: 1.0 mm (.040”) 308L Gas: Ar - CO
2
/ 19 L/min (40 CFH)
MPM / IPM Apk Abk PPS PWms Vpk COMMENTS
19.1 / 750 436 120 183 2.5 34.2
17.8 / 700 425 115 175 2.4 33.7
16.5 / 650 414 110 167 2.3 33.2
15.2 / 600 403 105 160 2.3 32.7
14.0 / 550 391 100 152 2.2 32.1
12.7 / 500 380 95 145 2.1 31.6
11.4 / 450 370 86 136 2.0 31.1
10.2 / 400 360 78 128 2.0 30.6
8.9 / 350 350 69 119 1.9 30.3
7.6 / 300 340 60 110 1.9 29.5
6.7 / 265 330 54 100 1.8 29.0
5.7 / 225 320 48 90 1.8 28.6
4.7 / 185 310 41 80 1.7 28.1
3.8 / 150 300 35 70 1.7 27.7
2.8 / 110 290 29 60 1.6 27.2
8-10. Program 8 – 1.2 mm 308L (.045”), 98-2 Argon-CO
2
Wire Size/Type: 1.2 mm (.045”) 308L Gas: Ar - CO
2
/ 19 L/min (40 CFH)
MPM / IPM Apk Abk PPS PWms Vpk COMMENTS
18.6 / 735 491 186 274 3.5 36.0
17.1 / 675 480 175 210 3.4 34.8
15.7 / 620 464 164 196 3.3 33.6
14.3 / 565 458 153 183 3.2 32.5
12.9 / 510 446 141 169 3.1 31.3
11.4 / 450 435 130 155 3.0 30.1
10.0 / 395 422 119 141 2.9 29.9
8.6 / 340 410 108 128 2.8 29.7
7.1 / 285 397 96 114 2.6 29.4
5.7 / 225 385 85 100 2.5 29.2
5.1 / 200 379 79 92 2.3 29.1
4.4 / 175 373 73 85 2.2 29.1
3.8 / 150 366 66 71 2.0 29.0
3.2 / 125 360 60 70 1.8 29.0
2.5 / 100 354 54 62 1.6 28.9
