8-11. Program 1 – 1.2 mm Metal Core (.045”), 95-5 Argon-CO
2
The next 8 programs are available after changing software wiretype (see Section 14-10).
Note
Wire Size/Type: 1.2 mm (.045”) Metal Core
Gas: Ar - CO
2
/ 19 L/min (40 CFH)
MPM / IPM
Apk
Abk
PPS
PWms
Vpk
COMMENTS
19.1 / 750
525
160
211
2.9
31.6
17.8 / 700
515
155
205
2.9
31.3
16.5 / 650
505
150
199
2.9
31.0
15.2 / 600
495
145
193
2.9
30.8
14.0 / 550
485
140
186
2.8
30.5
12.7 / 500
475
135
180
2.8
30.3
11.4 / 450
462
124
172
2.7
30.3
10.2 / 400
450
113
165
2.7
30.4
8.9 / 350
437
101
157
2.6
30.4
7.6 / 300
425
90
149
2.5
30.5
6.4 / 250
381
81
138
2.2
28.8
5.1 / 200
338
72
127
2.0
27.2
3.8 / 150
294
62
116
1.7
25.5
2.5 / 100
250
53
105
1.5
23.9
1.3 / 50
206
44
94
1.2
22.2
8-12. Program 2 – 1.4 mm Metal Core (.052”), 95-5 Argon-CO
2
Wire Size/Type: 1.4 mm (.052”) Metal Core
Gas: Ar - CO
2
/ 19 L/min (40 CFH)
MPM / IPM
Apk
Abk
PPS
PWms
Vpk
COMMENTS
18.1 / 715
562
194
206
3.8
34.0
17.8 / 700
560
190
206
3.7
33.9
16.5 / 650
551
175
208
3.5
33.7
15.2 / 600
543
160
210
3.3
33.5
14.0 / 550
534
145
211
3.0
33.2
12.7 / 500
525
130
213
2.8
33.0
11.4 / 450
512
121
199
2.7
32.2
10.2 / 400
500
113
185
2.7
31.5
8.9 / 350
487
104
171
2.6
30.7
7.6 / 300
475
95
157
2.5
29.9
6.4 / 250
427
82
142
2.4
28.2
5.1 / 200
380
70
127
2.3
26.6
3.8 / 150
332
57
111
2.2
24.9
2.5 / 100
284
45
96
2.1
23.3
2.2 / 90
272
42
92
2.1
22.9
