8-3. Program 1 – 1.2 mm Steel (.045”), 98-2 Argon-Oxy
Wire Size/Type: 1.2 mm (.045”) Steel Gas: Ar - Oxy / 19 L/min (40 CFH)
MPM / IPM Apk Abk PPS PWms Vpk COMMENTS
19.1 / 750 540 159 263 3.1 34.5
17.8 / 700 530 150 250 3.0 33.9
16.5 / 650 520 141 237 2.9 33.3
15.2 / 600 510 133 225 2.9 32.7
14.0 / 550 500 124 212 2.8 32.0
12.7 / 500 490 115 200 2.8 31.4
11.4 / 450 480 110 187 2.7 31.0
10.2 / 400 470 105 175 2.7 30.6
8.9 / 350 460 100 162 2.6 30.2
7.6 / 300 450 95 150 2.6 29.8
6.4 / 250 422 82 132 2.4 28.7
5.1 / 200 395 69 114 2.3 27.6
3.8 / 150 367 56 96 2.1 26.4
2.5 / 100 340 43 78 2.0 25.3
1.3 / 50 312 30 60 1.8 24.2
8-4. Program 2 – 1.0 mm Steel (.040”), 80-20 Argon-CO
2
Wire Size/Type: 1.0 mm (.040”) Steel Gas: Ar - CO
2
/ 19 L/min (40 CFH)
MPM / IPM Apk Abk PPS PWms Vpk COMMENTS
17.9 / 705 471 90 206 2.3 38.4
17.8 / 700 470 90 205 2.3 38.4
16.5 / 650 460 87 196 2.3 38.2
15.2 / 600 450 85 188 2.3 38.0
14.0 / 550 440 82 179 2.2 37.7
12.7 / 500 430 80 170 2.2 37.5
11.4 / 450 410 77 160 2.1 36.1
10.2 / 400 390 75 150 2.1 34.8
8.9 / 350 370 72 140 2.0 33.4
7.6 / 300 350 70 130 2.0 32.1
6.4 / 250 355 62 111 1.8 32.3
5.1 / 200 360 55 92 1.6 32.5
3.8 / 150 365 47 73 1.4 32.6
2.5 / 100 370 39 53 1.2 32.8
