DCA800SSK2 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #0 (09/03/09) — PAGE 87
BATTERY ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 0165719052 BATTERY 4
2 C9109100704 BATTERY SHEET 4
3 0805006404 BATTERY BAND 1
4 0805007804 BATTERY BAND 2
5 0805006504 BATTERY BOLT 6
6 0037808000 WING NUT 6
7 0040008000 WASHER, LOCK 6
8 0041608000 WASHER, FLAT 6
9 C5347800504 BATTERY CABLE 1
10 C5347800404 BATTERY CABLE 1
11 7522280904 BATTERY CABLE 2
12 C5347601404 BATTERY CABLE 1
13 C5347400104 EARTH CABLE 1
14 0347010030 HEX HEAD BOLT 8
15 0208110000 HEX NUT 8
16 0845040114 TERMINAL CAP (+) 4
17 0845041004 TERMINAL CAP (-) 4
18 C5347601304 BATTERY CABLE 1
19 C5347601204 BATTERY CABLE 1
