PAGE 16 — DCA800SSK2 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #0 (09/03/09)
GENERATOR
The MQ Power Model DCA800SSK2 is a 640 kW generator
(Figure 3) that is designed as a high quality portable
(requires a trailer for transport) power source for telecom
sites, lighting facilities, power tools, submersible pumps
and other industrial and construction machinery.
ENGINE OPERATING PANEL
The “Engine Operating Panel” is provided with the following:
Tachometer 
Emergency Stop Switch 
Water Temperature Gauge 
Oil Pressure Gauge 
Charging Ammeter Gauge 
Fuel Level Gauge 
Pilot Lamp 
PreHeat Lamp 
Engine Speed Switch 
Battery Switch 
Engine Alarm Lamps (6)

GENERATOR CONTROL PANEL
The “Generator Control Panel” is provided with the following:
Frequency Meter (Hz)

AC Ammeter (Amps)

AC Voltmeter (Volts)

Ammeter ChangeOver Switch

Voltmeter ChangeOver Switch

Voltage Regulator

Panel Light/Panel Light Switch

3Pole, 2500 amp Main Circuit Breaker 
“Control Box” (located behind the Gen. Control Panel) 
Automatic Voltage Regulator •
Current Transformer •
OverCurrent Relay •
Voltage Rectifi er •
Starter Relay •
Engine Controller (Computer Controlled) •
Voltage ChangeOver Board •
OUTPUT TERMINAL PANEL
The “Output Terminal Panel” is provided with the following:
Three 240/139V output receptacles (CS6369), 50A 
Three auxiliary circuit breakers, 50A 
Eight output terminal lugs (3Ø power) 
Battery Charger (Optional) 
Water Heater (Optional)

OPEN DELTA EXCITATION SYSTEM
The DCA800SSK2 generator is equipped with the state
of the art “OpenDelta” excitation system. The open delta
system consist of an electrically independent winding wound
among stationary windings of the AC output section.
There are four connections of the open delta A, B, C and
D. During steady state loads, the power from the voltage
regulator is supplied from the parallel connections of A to
B, A to D, and C to D. These three phases of the voltage
input to the voltage regulator are then rectifi ed and are the
excitation current for the exciter section.
When a heavy load, such as a motor starting or a short
circuit occurs, the automatic voltage regulator (AVR)
switches the confi guration of the open delta to the series
connection of B to C. This has the effect of adding the
voltages of each phase to provide higher excitation to the
exciter section and thus better voltage response during the
application of heavy loads.
The connections of the AVR to the AC output windings are
for sensing only. No power is required from these windings.
The opendelta design provides virtually unlimited excitation
current, offering maximum motor starting capabilities. The
excitation does not have a “fi xed ceiling” and responds
according the demands of the required load.
ENGINE
The DCA800SSK2 is powered by a 6 cylinder, water
cooled, direct injection, turbocharged airtoair KOMATSU
SAA6D170E3 Diesel Engine. This engine is designed to
meet every performance requirement for the generator.
Reference Table 2 for engine specifi cations.
In keeping with MQ Power’s policy of constantly improving
its products, the specifi cations quoted herein are subject
to change without prior notice.
ELECTRIC GOVERNOR SYSTEM
The electric governor system controls the RPMs of the engine.
When the engine demand increases or decreases, the
governor system regulates the frequency variation to ±.25%.
EXTENSION CABLES
When electric power is to be provided to various tools or
loads at some distance from the generator, extension cords
are normally used. Cables should be sized to allow for
distance in length and amperage so that the voltage drop
between the generator and point of use (load) is held to
a minimum. Use the cable selection chart (Table 6) as a
guide for selecting proper extension cable size.
